Parts for Mariner 15A HP Reverse Lock
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| #1 | 80236M | LEVER, LOCK/RELEASE (1 required per assembly) SERIAL 00000000-00012755 |
 |
|
80236M - LEVER,NLA [ More info ] Unavailable |
| #1 | 82880M | LEVER, LOCK/RELEASE (1 required per assembly) SERIAL 00012756-09999999 |
|
|
82880M - LEVER,NLA [ More info ] Unavailable |
| #2 | 24-82098M | SPRING, LEVER RETURN (1 required per assembly) |
|
|
24-82098M - SPRING,NLA [ More info ] Unavailable |
| #3 | 80235M | ROD, REVERSE LOCK LEVER (1 required per assembly) |
|
|
80235M - ROD,NLA [ More info ] Unavailable |
| #4 | 17-81894M | PIN (1 required per assembly) SERIAL 00006921-09999999 |
|
17-81894M - PIN [ More info ] Unavailable |
|
|
|
17-18945M - Pin, NLA [ More info ]
|
| #5 | 80233M | HOOK, REVERSE LOCK-REAR (1 required per assembly) |
|
|
80233M - HOOK,NLA [ More info ] Unavailable |
| #6 | 24-82104M | SPRING, REVERSE LOCK (1 required per assembly) |
|
|
24-82104M - SPRING,NLA [ More info ] Unavailable |
| #7 | 17-81881M | SHAFT, REVERSE LOCK (1 required per assembly) |
|
|
17-81881M - PIN,NLA [ More info ] Unavailable |
| #8 | 18-82125M | PIN, REVERSE LOCK SHAFT (2 required per assembly) SERIAL 00000000-00009770 |
|
|
18-82125M - Cotter Pin, NLA [ More info ]
|
| #9 | 80234M | HOOK, REVERSE LOCK-FRONT (1 required per assembly) |
|
|
80234M - HOOK,NLA [ More info ] Unavailable |
| #10 | 10-81702M | SCREW, REVERSE LOCK (2 required per assembly) |
|
|
10-81702M - SCREW,NLA [ More info ] Unavailable |
| #11 | 23-81966M | COLLAR, REVERSE LOCK SCREW (2 required per assembly) |
|
|
23-81966M - BUSHING,NLA [ More info ] Unavailable |
| #12 | 17-82785M | TILT LOCK PIN ASS'Y (SHORT) (1 required per assembly) |
|
17-82785M - TILT PIN [ More info ] Unavailable |
|
|
|
17-80266M - Tilt Pin [ More info ]
|
| #12 | 17-80266M | TILT LOCK PIN ASS'Y (LONG) (1 required per assembly) |
| #13 | 80640M | STOPPER PLATE (1 required per assembly) SERIAL 00000000-00012755 |
|
|
80640M - STOP,NLA [ More info ] Unavailable |
| #13 | 82857M | STOPPER PLATE (1 required per assembly) SERIAL 00012756-09999999 |
|
|
82857M - Stopper, NLA [ More info ]
|
| #14 | 17-82141M | PIN (1 required per assembly) SERIAL 00000000-00012755 |
|
|
17-82141M - Roll Pin [ More info ]
|
| #14 | 17-82144M | PIN (1 required per assembly) SERIAL 00012756-09999999 |
|
|
17-82144M - Pin, Roll [ More info ]
|
| #15 | 24-82099M | SPRING, TILT LOCK PIN (1 required per assembly) |
|
|
24-82099M - Spring, Tilt Lock Pin,NLA [ More info ]
|
| #16 | 17-81150M | SHAFT, TILT STOP (1 required per assembly) |
  |
|
17-81150M - Pin, Tilt Stop, NLA [ More info ]
|
| #17 | 80641M | KNOB, TILT STOP (1 required per assembly) |
|
80641M - KNOB [ More info ] Unavailable |
|
|
|
95426M - Tilt Stop Knob, NLA [ More info ] Unavailable |
| #18 | 17-82148M | PIN, TILT STOP KNOB (1 required per assembly) |
|
|
17-82148M - Pin, Roll, NLA [ More info ]
|
| #19 | 53-82330M | CIRCLIP (1 required per assembly) SERIAL 00006921-09999999 |
|
|
53-82330M - E-Ring, NLA [ More info ]
|
| #20 | 18-82736M | PIN, COTTER (1 required per assembly) SERIAL 00000000-00006920 |
|
18-82736M - COTTER PIN Note: Priced Individually [ More info ] Unavailable |
|
|
18-82126M - COTTER PIN Note: Priced Individually [ More info ] Unavailable |
|
|
|
18-43089M - PIN-COTTER,NLA [ More info ] Unavailable |
