Sierra Marine Parts Catalog: Mercruiser

< Previous Page  Next Page >
R WATER PUMP ASSEMBLY
Sequence
Description
Part #
O.E. #
Qty.
1
Guide, Water Tube
18-3109
23-29804
1
2
Grommet, Water Tube Guide
18-3110
26-38970
1
3
O-Ring
18-7158
25-30613
1
4
Seal, Dust Cover
18-7426
25-30271
1
5
Nut, Housing Retainer
18-3723
11-45592
1
6
Nut, Housing Retainer
18-372211-20361, 11-35888
2
7
Washer, Housing Retainer
18-4275
12-29245
3
8
Bolt, Housing Retainer
18-3226
10-30720
1
9
Washer, Housing Retainer
18-4270
12-36001
1
10
Housing, Impeller
18-3116
46-96148A1
1
11
Cup, Impeller
18-3114
48752
1
12
Impeller
18-3017
47-89984
1
13
Key, Impeller
N/A
28-56654
1
14
Gasket, Impeller
18-2915
27-85609-1
1
15
Wear Plate, Impeller
18-3117
32435
1
16
Gasket Wear Plate
18-2914
27-85608-1
1
17
Pin, Alignment
18-3227
17-35973
1
18
Base Assembly
18-3417
46-57234A1
1
19
Oil Seal, Base Assembly
18-2013
26-16977
1
20
Oil Seal, Base Assembly
18-2014
26-89238
1
21
O-Ring, Base Assembly
18-7162
25-33145
1
22
Gasket, Base Assembly
18-2826
27-85610-1
1
633
