Sierra Marine Parts Catalog: Mercury Mariner
MARINER DIAPHRAGMS (Japanese Models)
Model
S/N Code
S/N
Diaphragms
Model
S/N Code
S/N
Diaphragms
5C
6E3
ALL
28
644
M-664-151346 & UP
➁
6H8
ALL
6C
30
689
ALL
➁
6D
6H6
ALL
40 TC
6E9
ALL
➁
677
ML-677-316416 & UP
8B
40A APE
676
M-676-A00346 -- 001990
8B
677
M-677-012921 & UP
676
M-676-A001991 & UP
40A APE
➁
8C
6G1
ALL
40A APE
676
ML-676-A41356 -- 302250
682
ALL
9.9C
676
ML-676-A302251& UP
40A APE
➀
➁
15A
651
ALL
40A APE
676
E-676-A10121 -- 100355
684
ALL
15C
676
E-676-A100356 & UP
40A APE
➀
➁
20A APE
653
ALL
40A APE
676
EL-676-A50631 -- 400940
6A9
ALL
20C TPE
676
EL-676-A400941 & UP
40A APE
➁
➁
25A
648
EL-648-550230 & BELOW
40B TPE
676
ALL
➁
648
EL-648-550231 & UP
25A
40C TC
6E9
ALL
➁
➁
25A
648
E-648-26825 & BELOW
48
670
ML-670-302510 & BELOW
648
E-648-26826 & UP
25A
48
670
ML-670-302511 -- 311995
➁
➁
25A
648
ML-648-304174 & BELOW
48
670
M-670-02640 & BELOW
648
ML-648-304174 & UP
25A
48
670
M-670-02641 -- 002160
➁
➁
25A
648
M-648-19025 & BELOW
W48
670
ML-670-311996 & UP
648
M-648-19026 & UP
25A
670
M-670-002161 & UP
W48
➁
25C TPE
695
EL-695-550101 -- 555959
55
663
EL-663-315379 -- 317710
➁
25C TPE
695
EL-695-555960 & UP
663
EL-663-317711 & UP
55
➁
695
E-695-250101 -- 253861
25C TPE
55
663
E-663-004041 -- 004317
➁
25C TPE
695
E-695-253862 & UP
663
E-663-004318 & UP
55
➁
695
ML-695-300101 -- 318173
25C TPE
55
663
ML-663-36475 & BELOW
➁
25C TPE
695
ML-695-318174 & UP
663
M-663-02730 & BELOW
55
695
M-695-000101 -- 023895
25C TPE
W55
663
ML-663-578278 -- 583880
➁
25C TPE
695
M-695-023896 & UP
663
ML-663-583881 & UP
W55
➁
644
EL-664-570795 & BELOW
28
60 2 CYL
6F0
ALL
28
644
EL-664-570796 & UP
675
EL-675-30101 -- 300280
60 2 CYL
➁
28
644
E-664-270310 & BELOW
60 2 CYL
675
EL-675-300281 -- 304180
➁
644
E-664-270311 & UP
28
60 2 CYL
675
EL-675-304180 & UP
➁
28
644
ML-664-451125 & BELOW
675
E-675-00101 -- 000180
60 2 CYL
644
ML-664-451126 & UP
28
60 2 CYL
675
E-675-00181 -- 001170
➁
➁
28
644
M-664-151345 & BELOW
60 2 CYL
675
E-675-001171 & UP
8' LENGTH COMPLETE FUEL LINE ASSEMBLIES
18-8010EP-1 SILVERADO 4000 Premium
3/8"
FUEL LINE ASSEMBLY
FUEL
PRIMER
FUEL
TANK
CONNECTOR
BULB
CONNECTOR
CONNECTOR
✱
✱
(SOLD SEPARATELY)
FUEL LINE ASSEMBLY COMPONENTS
8' LENGTH COMPLETE FUEL LINE ASSEMBLIES
18-8012EP-1 SILVERADO 4000 Premium
OE# 32-858114Q08,
3/8"
32-858114K08
FUEL LINE ASSEMBLY
HOSE BARB
PRIMER
HOSE BARB
BULB
FUEL LINE ASSEMBLY COMPONENTS
✱
✱
Has 1/4" NPT threaded fitting on engine end and �" NPT threaded fitting on the tank end. Primer bulb is included in this 8ft. (2.44 m) assembly.
Fits various applications using the older style twist type disconnects at the engine end and either a bayonet or thread-in fitting on the tank end.
8' LENGTH COMPLETE FUEL LINE ASSEMBLIES
18-8024EP-1 SILVERADO 4000 Premium
OE# 32-858104Q08,
3/8"
FUEL LINE ASSEMBLY
32-858104K08
HOSE BARB
PRIMER
FUEL
BULB
CONNECTOR
FUEL LINE ASSEMBLY COMPONENTS
✱
✱
Has standard quick connect type fitting on engine end and �" NPT threaded fitting on the tank end. Primer bulb is included in this 8 ft. (2.44 m) assembly.
Fits Force 40 HP and larger (1993 & Newer), Force 9.9/15/25HP (1998), and all Mercury/Mariner
outboards using clip on type disconnect at engine ends and a tank with threaded fuel pickup fitting.
✱ Tanks and Engines for picture purpose only.
329
