Sierra Marine Parts Catalog
Weather Resistant Illuminated Rocker Switches
ON-ON SPDT
*Dependent pilot lights - each light illuminates in "on" position
� Use to control circuit from 2 locations
� Certified to IP 66 and IP 68 - protected against dust,
prolonged spray and submersion
� Supplied with neoprene mounting gasket
� Removable actuators
Snap in lens of choice
� Brass blade terminals, silver contacts
Kit includes 2 of each color
**RK19580K
Rated: 20 amps @12 VDC
Amber Clear Green Red
Rocker Switch Mounting Brackets For Installing Two Or More Rocker Switches
� Fits Sierra Standard and Contura� Rocker Switches
� Sections snap together without tools
� Mounting hole for 2 end unit set - 2.02" (51.31 mm) wide x 1.90" (48.26 mm) high add 1.03" (26.16 mm) for additional sections
**UN19700
**UN19710
**UN19720
Blank Cover
1 Center section
Two end sections
**UN19750
Kit contains:
2 - **UN19740
End sections
1 - **UN19710
Center section
**UN19740
**UN19730
1 - **UN19700
Blank cover
1 End section
2 Center sections
Interior and Rv Style Switches
Narrow Body Rocker Switch
Narrow Body Rocker Switches
ON - OFF SPST
ON - OFF SPST
� For use in RK22070 panel
� Fits 7/16" X 1 1/4" cut out
� Fits .550" X 1.125" cut out
� Blade Terminals
� Blade Terminals
� 20 Amp @ 12 VDC
� 10 Amp @ 12 VDC
**RK21880
Non Illuminated
**RK19640
**RK21890
Glows Red in ON position
*RK19642
Surface Mount Illuminated
Narrow Body Rocker Switch
Rocker Switches
ON - OFF SPST
OFF-ON SPST
� Fits .550" x 1.125" cut out
� Illuminates in ON position
� Blade Terminals
� Mount in 1/2" round holes
� 10 Amp @ 12 VDC
� Brass blade terminals
� Glows red in ON position
� 16 Amp @ 12 VDC
**RK21420
Red
**RK19630
**RK21430
Green
*RK19632
40
*BULK - 100 pcs. per carton
**CLAMSHELL
