Sierra Marine Parts Catalog

343 18-6018 ANODE Replaces: 327606 1983-89 2HP, For Motor Leg ➂ 18-6017 ➀ 18-6017A ➁ 18-6100 ANODE Replaces: 173029, 123009 (1981-91) 9.9-115 HP For use on gearcase and transom bracket assembly ➂ 18-6020 ANODE Replaces: 976669 (1969-89) Kit for V4 & V6 ➂ 18-6027 ANODE Replaces: 392123 (1982-98) 40-300 HP Front Lower Leg Extension ➂ 18-6024 ➀ 18-6024A ANODE Replaces: 393023, 436745 (1982-87) 60-300 HP For use on gearcases ➂ 18-6095 ➀ 18-6095A ANODE Replaces: 431708 (1988-90) 45-300 HP For use on Prop Shaft Bearing Carrier ➂ 18-6025 ANODE Replaces: 433458, 398331 (1987-92) 60-300HP For use on Stern Bracket ➀ Aluminum ➁ Magnesium ➂ Zinc ➂ 18-6115 ANODE TRANSOM BRACKET Replaces: 433580 For: 60-225 (1991-93) For use on Stern Bracket ➁ 18-6026 ANODE Replaces: 392462 For exhaust housing, 2 & 3 Cyl. (1984-99) OUTBOARD — JOHNSON/EVINRUDE (OMC/BRP) - Drive System/Gear Housing Seal Kits Zinc is for saltwater only applications. Magnesium is for fresh water only applications. Aluminum is for brackish water, or if boat is used in both fresh and salt environments. 18-2623 LOWER UNIT SEAL KIT Replaces: 439141 —  CONTAINS — Part # Desc. O.E. # Qty. 18-0110 Shift Housing Gasket 314082 1 18-2001 Seal 330137 2 18-2002 Seal 320862 2 18-2026 Seal 321453 2 18-2061 Seal 329922 1 18-2062 Seal 329923 1 18-2377 Screw 316563 4 18-2378 Magnetic Drain Screw 318544 1 18-2536 O-Ring 315788 1 18-2557 Impeller Gasket 338484 1 18-4248 Washer 311598 2 18-7109 O-Ring 317178 1 18-7120 O-Ring 307853 1 18-7127 O-Ring 313446 1 18-7130 O-Ring 314728 1 18-7133 O-Ring 305123 2 18-7137 O-Ring 318372 2 18-7142 O-Ring 322119 1 18-7144 O-Ring 333572 3 18-7145 O-Ring 332584 1 18-7475 Washer 328743 4 18-8300 Seal 341280 1 18-8301 Seal 341281 1 18-2656 LOWER UNIT SEAL KIT Replaces: 396350 —  CONTAINS — Part # Desc. O.E. # Qty. 18-2025 Oil Seal 318971 1 18-2028 Oil Seal 321480 2 18-2029 Oil Seal 321481 2 18-4248 Washer 311598 2 18-7100 O-Ring 301877 1 18-7104 O-Ring 308627 1 18-7120 O-Ring 307853, 322598 1 18-7139 O-Ring 319085 1 18-7145 O-Ring 333572 2 18-2657 LOWER UNIT SEAL KIT Replaces: 396352 —  CONTAINS — Part # Desc. O.E. # Qty. 18-0882 Shift Rod Gasket 304764 1 18-0108 Lower Gearcase Gasket 324449 1 18-3360 Impeller Housing Gasket 329390 1 18-7411 O-Ring — 1 18-2027 Oil Seal 321459 2 18-2031 Oil Seal 321787 1 18-2063 Oil Seal 330327 1 18-4248 Washer 311598 2 18-7100 O-Ring 301877 1 18-7145 O-Ring 333572 2 18-7475 Quad Ring 332583 OUTBOARD — JOHNSON/EVINRUDE (OMC/BRP) - Drive System/ Gear Housing Seal Kits
