STEERING
DUAL CABLE - SINGLE ENGINE ATTACHING KIT
DUAL ENGINE TIE BAR KITS
Tension‑compression only with both cables installed on the starboard
Dual cables are required for installations of 80 hp. (combined total of
side.
160 hp.) or higher.
DUAL CABLE ATTACHING KIT
TIE BAR EXTENSION
Fits Mercury/Mariner V‑6 outboards with single trim cylinder (1984 and prior).
Standard Tie Bar Extension Coupler. 15 in.(381 mm). For clearance problems see
optional extension couplers.
DUAL CABLE ATTACHING KIT
Fits Mercury/Mariner with standard cowling clearance. Outboard center line
distance between 23‑1/2 in. thru 27‑1/2 in. (597 mm thru 699 mm)
TIE BAR EXTENSION
Used to attach dual mechanical steering cables to the engine. The engine
furnished steering link rod is not a part of this kit.
Fits the Mercury F225 EFI FourStroke outboard.
Standard Tie Bar Extension Coupler. 18 in.(458 mm). For clearance problems see
optional extension couplers.
DUAL CABLE ATTACHING KIT
Fits Mercury/Mariner with standard cowling clearance. Outboard center line
distance between 26‑1/2 in. thru 30‑1/2 in. (673 mm thru 755 mm)
DUAL ENGINE TIE BAR
Fits Mercury / Mariner 70‑300 hp. outboards (1985 and Newer) and Force 90/120
hp. outboards (1996 and Newer).
Includes 15 in. (381 mm) extension coupler. Adjusts from 22 in. (560 mm) to 26‑1/2
in. (675 mm). See extension couplers for additional length.
Fits various Mercury/Mariner 70 thru 3.0 Litre outboards with two piece steering
arms.
US Quicksilver Product Guide
303
