FORCE OUTBOARD APPLICATION CHARTS
Length (ft/m)
Current MPH/KPH
Propeller Size
Matl
Blades
Style
Quicksilver P/N
OEM P/N
Hub System
High Perf.
49-56 / 79-90
13 1/2 X 24 RH
SS
3
Lightspeed
QS5124X
16994A46
(1)
High Perf.
52-61 / 84-98
13 1/2 X 26 RH
SS
3
Lightspeed
QS5126X
16996A46
(1)
(1) Use Flo-Torq II attaching hardware kit 835257Q1. Purchase separately.
(2) Extra Cup Version.
Force 85150 and All LDrives Pre 1995 No Thru or Thru Hub
Exhaust
85, 125 HP 19881989
90, 120 HP 19901994
90120 HP L Drive 19891991
150 HP 19891994
150 HP L Drive 1991
15 Tooth Spline
Propeller Size
Material
Blades
Style
Quicksliver P/N
Hub System
13 X 19 RH
AL
3
Black Diamond
48-FP686-4
Rubber Bushing
13-1/2 X 17 RH
AL
3
Black Diamond
48-FP685-3
Rubber Bushing
13-1/2 X 15 RH Cupped
AL
3
Black Diamond
48-FP669-3
Rubber Bushing
13-1/2 X 15 RH
AL
3
Black Diamond
48-FP692-3
Rubber Bushing
14 X 13 RH
AL
3
Black Diamond
48-FP743-2
Rubber Bushing
US Quicksilver Product Guide
85
