SeaStar Hydraulic Power Steering (Cont.)

93
®
MISCELLANEOUS
Outlet Check Valve (Power Pump)
Auto Flow Control (Twin Pump)
Crossover Pressure Relief
System Pressure Gauge Kit
Adapter Kit, Twin Disc #5050
Adapter Kit, Twin Disc #5061
Adapter Kit, MAN to V10 Pump
Tiller Bolt Kit (stainless steel)
Pressure Relief Valve (1250psi setting)
HELM OPTIONS
Add-A-Station/Autopilot Fittings Kit
Helm Remote Fill Kit (through-dash)
1.4 HELMS
(4.3 WHEEL TURNS WITH 9” STROKE CYLINDER)
SeaStar 1.4 - Front Mount Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 1.4 - Rear Mount Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 1.4 - Rear Mount Helm
(Above helm has 1” straight shaft.)
SeaStar 1.4 - Rear Mount Helm
HH5280-3
(Above helm has 1” tapered shaft.)
SeaStar 1.4 - Classic Helm
(Above helm has 3/4” tapered shaft.)
1.7 HELMS
(3.5 WHEEL TURNS WITH 9” STROKE CYLINDER)
SeaStar 1.7 - Front Mount Helm
SeaStar 1.7
- Front Mt. Commercial Helm
SeaStar 1.7 - Rear Mount Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 1.7 - Rear Mount Helm
(Above helm has 1” tapered shaft.)
SeaStar 1.7 - Sport Tilt Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 1.7 - Classic Tilt Helm
(Above helm has 3/4” tapered shaft.)
2.0 HELMS
(3.0 WHEEL TURNS WITH 9” STROKE CYLINDER)
SeaStar 2.0 Front Mount Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 2.0
Sport Tilt Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 2.0 Classic Tilt Helm
(Above helm has 3/4” tapered shaft.)
2.4 HELMS
(2.5 WHEEL TURNS WITH 9” STROKE CYLINDER)
SeaStar 2.4 - Front Mount Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 2.4
- Front Mt. Commercial Helm
SeaStar 2.4 - Rear Mount Helm
(Above helm has 3/4” tapered shaft.)
SeaStar 2.4 - Sport Tilt Helm
SeaStar 2.4 - Classic Tilt Helm
CAPILANO HELM
(1.8-3.5 WHEEL TURNS WITH 9” STROKE CYLINDER)
Capilano 1250V Helm
SEASTAR FRONT MOUNT HELM
MOUNTING OPTION KITS
SeaStar Round Bezel Kit
(Reduces helm protrusion by 3.75”)
SeaStar Backplate Kit
SeaStar 20° Dash Wedge Kit
SeaStar Helm Fill Kit
SERVICE ITEMS
SeaStar Power Steering Purge Kit
SeaStar Power Steering Purge Kit
SeaStar Oil (1 Gallon)
SeaStar Oil (1 Quart)
Steering Wheel Locknut
STEERING - Inboard (Hydraulic)
SEASTAR INBOARD STEERING COMPONENTS (Cont.):
See Page 148
