XTREME Steering

35
®
STEERING - Outboard (Mechanical)
NFB™ MECHANICAL
ROTARY STEERING SYSTEM:
New Helm - The patent pending helm has a complete
new gear train designed to provide smooth feel
minimal backlash and low effort at the wheel. It also
offers the smoothest NFB clutch release and has
a smaller footprint than the current 4.2 helm. All
castings are designed to reduce weight while offering
superior strength.
New Bezel - New style, patent pending bezel keeping
with the design of the SH91900 tilt and hydraulic
helm pump designs.
SSCX64 XTREME Cable - A brand new XTREME™
steering cable was designed specifically for this
system. This cable offers lower backlash and is more
efficient than a standard steering cable. It provides the
lowest ease of effort, a close "fit" of the core to liner for
lowest lost motion. The concept provides the "tight"
fit of core to liner yet allows area for lubrication. The
design of the helm allows higher loads to be placed
into the cable requiring this new design cable. There
is a quick connect feature on both the steering cable
and spent travel tube for easy, quick installation.
APPLICATIONS:
XTREME single cable steering systems are suitable for
most single-station boats with a single non-power
assisted outboard engine up to V6 and minimal
engine flutter or steering instability.
XTREME steering accepts steering wheels up to 16"
diameter.
Use either the 4.2 NFB dual rotary or Pro Rack dual
cable systems for boats with engine flutter or steering
instability.
Replaces nearly all SeaStar Solutions Safe-T steering
systems without dash modifications.
FEATURES:
• Smoothest and lowest steering effort mechanical
helm offered in the market place yet still offers
easy installation.
• Complete steering system including new helm,
high effeciency XTREME™ steering cable design
and new style bezel.
• Quick connect feature on both steering cable
and spent travel tube for easy quick installation.
• Installs in same mounting pattern and bracket
location as most current SeaStar Solutions rotary
steering systems.
• Smallest footprint possible to accomodate small,
tight dash helm stations.
• Made, designed and assembled in the USA.
Note: All SSCX XTREME Cables are designed to fit
only XTREME helms.
COMPLETE SYSTEM
XTREME™ NFB
Steering Kit
SSX176XX
COMPONENTS
XTREME™ NFB Helm, Bezel and
Hardware Kit
SHX7606 **
XTREME™ QC Steering Cable
SSCX64XX **
OPTIONS
XTREME™ Tilt NFB Helm
SHX97606 **
XTREME™ Non-NFB Helm, Bezel and
Hardware Kit
SHX7626 **
XTREME™ Tilt Non-NFB Helm
SHX97626 **
XTREME™ Tilt NFB Steering Kit
SSX177XX
SERVICE ITEMS
XTREME™ QC Steering Cable
SSCX64XX **
XTREME™ Bezel and Hardware Kit NFB
SBX76061 **
XTREME™ Bezel and Hardware Kit
Non-NFB
SBX76261 **
** Only offered to OEM builders as separate items.
