Control Cables (Utility, Vernier & DC Control)

222
®
UTILITY CABLE:
An easy-to-install, easy to operate, flexible push-pull
cable for remote control of choke, throttle, shut off,
fuel valves, vents and many other applications.
Available with both knob and T-handle.
Solid stainless steel core wire resists corrosion,
moves easily in HDPE liner.
HDPE outer casing for durability and best
resistance to UV and chemicals.
VERNIER CABLE:
Great for throttles or other applications where precise
control is desired. Push the button for fast easy setting
of approximate position, then turn the knob for micro
adjustment.
Positive, adjustable brake maintains settings
regardless of vibration or governor back pressure.
HDPE outer casing for durability and best
resistance to UV and chemicals.
FOR USE ON:
Remote control of choke, governor, throttle, fuel
valves, vents and other applications.
UTILITY:
WITH KNOB AND T-HANDLE:
Utility Cable (5’)
Utility Cable (10’)
Utility Cable (15’)
Utility Cable (20’)
Utility Cable (25’)
Utility Cable (30’)
Utility Cable (35’)
Utility Cable (40’)
VERNIER:
The vernier cable requires ordering 2 part numbers: a Vernier Cable
Head (which includes knob, button, panel body and fine adjustment
mechanism) PLUS a Cable, which attaches to the Cable Head.
Vernier Cable Head
Vernier Cable (5’)
Vernier Cable (10’)
Vernier Cable (15’)
Vernier Cable (20’)
Vernier Cable (25’)
Vernier Cable (30’)
Vernier Cable (35’)
Vernier Cable (40’)
CONDUIT FITTING KITS:
Use these (formerly known as Hub Adapter Kits) to mount utility cables
to mount in either bulkhead or clamp type applications.
Bulkhead Adapter Kit
Clamp Adapter Kit
Stop Collar
DC CONTROL:
Converts standard 3300/33C cable into a utility control. Install through
a panel or mount nearly anywhere with optional bracket.
DC Control
Uses CCX633xx *
3300/33C Type Cable
Mounting Bracket (stainless steel)
BULKHEAD ADAPTER KIT
CLAMP ADAPTER KIT
DC CONTROL 301916
MOUNTING BRACKET
3300/33C CABLE
CONTROL CABLES - Panel
UTILITY & VERNIER APPLICATIONS:
* CCX633 is the recommended 3300/33C cable for use with the DC control
