CH7500 Series

183
CONTROLS - Dual Function
®
CH7500 SERIES (LEVER ON RIGHT):
CH7500 series controls offer options that most top
mount controls in the market do not. Options include
trim (most outboards) or trim and tilt (most stern
drives) or the neutral lock out button. The lock out
button is great for center console boats where there is
a possibility the control can be bumped while passing
by knocking it into gear. The standard items on these
controls are the shapely and balanced hand grips
that give you a very smooth, yet solid feel, the neutral
safety switch and the neutral warm up button. These
controls can not only use the 3300/33C style control
cables they can also use Mercury style cables from
1965 to date including the Gen II, OMC/Johnson/
Evinrude/BRP control cables from 1979 to date.
This makes it one of the most desirable replacement
controls in the market today.
APPLICATION:
Dual-function control — one lever controls
throttle AND shift. For nearly any engine.
FEATURES:
Superior feel and function for most outboards,
stern drives & inboards.
Dual function lever controls both throttle and
shift of one engine.
Neutral safety offers start-in-gear protection
(standard).
Optional Trim in the handle for each model.
Neutral engine warm-up feature (standard).
Optional tilt switch available.
Friction adjustment feature included.
“Easy-On” cable design accepts virtually every
type of OEM and 3300/33C type cable.
Easily adapted to push or pull cable actuation
mode.
Mechanical advantage 2.38:1
Meets/exceeds all applicable standards.
Made in the U.S.A.
Pictured
ENGINE CONTROLS
Single Top-Mount Control - Lever on the Right
Single Top-Mount, Chrome Handle,
Chrome Cover, Chrome and Black
Inserts (without trim)
Single Top-Mount, Chrome Handle,
Chrome Cover, Chrome and Black Inserts,
with Trim
Single Top-Mount, Chrome Handle,
Chrome Cover, Chrome and Black Inserts,
with Trim & Tilt
Single Top-Mount Control with Neutral Interlock
Lever on the Right Side
Single Top-Mount, Chrome Handle,
Chrome Cover, Chrome and Black Inserts,
with Neutral Interlock (without trim)
Single Top-Mount, Chrome Handle,
Chrome Cover, Chrome and Black Inserts,
with Trim, with Neutral Interlock
Single Top-Mount, Chrome Handle,
Chrome Cover, Chrome and Black Inserts,
with Trim & Tilt, with Neutral Interlock
SERVICE ITEMS
Dome Cover-CH7500/CH7600-Chrome
Insert Kit CH7500-with & w/o Tilt hole-
Black (2 inserts)
Neutral Warm-up Button Kit-
CH7500/CH7600
Tilt Switch-CH7500/CH7600-with
Chrome & Black Insert Kit
Cable Nest And Connection Kit
Neutral Safety Switch
NOTE: When properly installed, these engine controls will
connect to outboard, stern drive and inboard engines, utilizing
Mercury/Mariner
®
and OMC
®
OEM type control cables as well as
universal 3300/33C type cables and engine connection kits.
SeaStar Solutions
Recommends Using
Cables With This
Control
