Mechanical Steering Kit Overview

18
®
NFB = No FeedBack, an exclusive SeaStar Solutions feature built into the helm to fight prop torque feedback.
Steering Wheel Turns Lock-to-lock = steering wheel revolutions from hard over port to hard over starboard.
NFB should not be used with autopilots or power assisted steering.
MECHANICAL STEERING KIT OVERVIEW:
NFB™ 4.2 TILT SS157xx (SINGLE)
The kit contains the following:
No FeedBack Tilt Helm
Tilt Mechanism
Steering Cable
Hardware & Instruction sheets
Kit sizes:
11-25 feet
SSC62xx can be used as a replacement cable.
APPLICATIONS:
NFB 4.2 Tilt single-cable systems are suitable for most single-station
boats with a single non-power-assisted outboard engine up to V-6 and
minimal engine flutter or steering instability.
4.2 steering
wheel turns
lock-to-lock
XTREME™ NFB™ SSX176XX
The kit contains the following:
1 - SHX7606
XTREME™ NFB Helm, Bezel
and Hardware Kit
1 - SSCX64XX
XTREME ™ QC Steering Cable
Hardware & Instruction sheets
Kit sizes:
11-25 feet
SSCX64XX can be used as a replacement cable.
APPLICATIONS:
XTREME NFB single-cable systems are suitable for most single-station
boats with a single non-power-assisted outboard engine up to V-6 and
minimal engine flutter or steering instability. Use dual cable system for
boats with engine flutter or steering instability.
XTREME™ NFB™ TILT SSX177XX
The kit contains the following:
1 - SHX97606
XTREME ™ Tilt NFB Helm
1 - SH91800
Sport Tilt Mechanism
1 - SSCX64XX
XTREME™ QC Steering Cable
Hardware & Instruction sheets
Kit sizes:
11-25 feet
SSCX64XX can be used as a replacement cable.
APPLICATIONS:
XTREME NFB Tilt single-cable systems are suitable for most single-
station boats with a single non-power-assisted outboard engine up
to V-6 and minimal engine flutter or steering instability.
STEERING - Mechanical Kit Overview
NFB™ 4.2 SS147xx (SINGLE)
The kit contains the following:
No FeedBack Helm
90 Degree Bezel Kit
Steering Cable
Hardware & Instruction sheets
Kit sizes:
10-20
feet (Single cable)
SSC62xx can be used as a replacement cable.
APPLICATIONS:
NFB 4.2 single-cable systems are suitable for most single-station boats
with a single non-power-assisted outboard engine up to V-6 and
minimal engine flutter or steering instability. Use dual cable system for
boats with engine flutter or steering instability.
4.2 steering
wheel turns
lock-to-lock
