SeaStar Hydraulic Steering Options Based on Boat Type (Cont.)

17
®
STEERING OPTIONS BASED ON BOAT TYPE:
COMMERCIAL/WORK/RESCUE/RACE:
Any of the boats described above used in a more severe
environment. Take special care when selecting a system for these
boats to ensure that you have both comfortable and reliable
steering for your boating conditions.
PONTOON:
Twin or Triple tube boats. Single
and dual engine capable. Generally
speeds do not exceed 60 MPH.
Note: High steering loads when
equipped with engines over 115 HP.
Pontoon System: SeaStar (up to 700 HP) —
several configurations available
Easiest Steering: SeaStar P/A
BASS BOAT:
Single engine designed
specifically for fishing in
protected waters with a flat-
bottomed hull. Generally
performance oriented with
speeds that can exceed 60 MPH.
Outboard — Single Engine:
Basic System: SeaStar Pro
Maximum Steering Precision: SeaStar PRO
Easiest Steering: SeaStar P/A PRO
Outboard — Single Engine:
Basic System: SeaStar (up to 350 HP)
Easiest Steering: SeaStar P/A
Maximum Steering Precision: SeaStar PRO
Outboard — Dual or Triple Engine:
Basic System: SeaStar (up to 700 HP)
Extra Heavy Duty System: SeaStar Tournament Series Cylinders (up
to 900 HP, triple engines)
Easiest Steering: SeaStar P/A
Stern Drive:
Basic System: SeaStar Stern Drive
Heavy Duty System: Hynautic (K-5 Cylinder)
Easiest Steering: SeaStar P/A
Inboard:
Basic System: SeaStar 2-line
Heavy Duty System: Capilano 2-line
Extra Heavy Duty System: Hynautic 3-line
Easiest Steering: SeaStar P/A or SeaStar Power Steering
CENTER CONSOLE:
Boats with the control station
located on the center line of the
boat. Designed specifically for
fishing, may have single or multiple
engines. Boat speeds are generally
slower than 65 MPH.
Outboard — Single Engine:
Basic System: BayStar (up to 150 HP)
Easier Steering: SeaStar (up to 350 HP)
Easiest Steering: SeaStar P/A
Outboard — Dual or Triple Engine:
Basic System: SeaStar (up to 700 HP)
Extra Heavy Duty System: SeaStar Tournament Series Cylinders (up
to 900 HP, triple engines)
Easiest Steering: SeaStar P/A
Stern Drive:
Basic System: SeaStar Stern Drive
Heavy Duty System: Hynautic (K-5 Cylinder)
Easiest Steering: SeaStar P/A
Inboard:
Basic System: SeaStar 2-line
Heavy Duty System: Capilano 2-line
Extra Heavy Duty System: Hynautic 3-line
Easiest Steering: SeaStar P/A or SeaStar Power Steering
FISH BOAT:
Boat primarily designed and equipped
for offshore fishing. May be rigged
with a second station and have single
or multiple outboards. Speeds are
generally slower than 50 MPH.
CATAMARAN:
Twin hull vessels. Typically twin
engine boats where the use of a
mechanical tie bar is not possible.
Speeds do not exceed 60 MPH.
Catamaran System: SeaStar (up to 700 HP) —
several configurations available
Easiest Steering: SeaStar P/A
STEERING - Options (Boat Type)
CENTER CONSOLE
