Cylinders (Cont.)

140
®
Adjustable threaded design
Maximum stroke indicator
Robust wipers
and seals
Secondary end gland
retention using plate bolts
Stainless steel wear washer
Bolt-on stainless steel tie
bar plates (reversible)
Adjustable 90º
stainless steel ORB
elbow fittings
Robust barrel/Shaft/
Support Brackets
Anodized aluminum body
Stainless Steel
Rod Ends
SEASTAR TOURNAMENT SERIES
CYLINDERS
PART NO.
ORDER INFORMATION
Outboard Tournament Series Cylinder, Front Mount
Outboard Tournament Series Cylinder, Front Mount,
c/w Single Engine Hardware Kit
Extreme heavy duty cylinders and tie bars designed for
primarily high performance multiple engine applications.
Also available for single engine applications. This heavy
duty universal cylinder features reversable bolt on stainless
steel tie bar plates that are suitable for use with all SeaStar
Helms and SeaStar Power Assist.
SEASTAR SIDE MOUNT
OUTBOARD CYLINDER
PART
NUMBER
DESCRIPTION
O/B Cylinder Kit, Side Mount, Unbalanced
This cylinder is suitable for installation in shallow splashwells and
use on engines fitted with power steering. This unbalanced cylinder
is 4.8/5.7 turns lock-to-lock. Typical applications include center
console fishboats and cruisers. For single and multiple outboard
engine installations with total power to 600 HP in counter rotating
application.
NOTE: Not for use with SeaStar Pro helms.
SEASTAR SPLASHWELL MOUNT
OUTBOARD CYLINDER
PART
NUMBER
DESCRIPTION
Outboard Splashwell Mount Cylinder
This cylinder is a light duty alternative to front & side mount
cylinders. It is unbalanced with 5.5/6.5 turns lock-to-lock and fits
engines with/without support (steering) tube. The splashwell mount
cylinder is for single & multiple engine capability and has total power
to 600 HP in counter rotating application. It can be transom or hull
mounted cylinder.
NOTE: Not for use with SeaStar Pro helms.
STEERING - Cylinders
