Cylinders

139
®
SEASTAR FRONT MOUNT
OUTBOARD CYLINDERS
PART
NUMBER
DESCRIPTION
Outboard Cylinder Kit, Front Mount
Outboard FM PP Cylinder
HC5345RED-3
Outboard FM PP Cylinder (Red)
Outboard FM PP Cylinder (Silver)
Outboard FM PP Cylinder (Honda)
Outboard FM PP Cylinder
Outboard FM PP Cylinder
Outboard FM PP Cylinder Silver
SeaStar Outboard Hydraulic Steering offers three models of
steering cylinders to suit most applications. The standard
and most commonly used model is the Front Mount
Steering Cylinder HC5345-3/47/48/58. Before ordering it
is necessary to determine the best possible application for
your boat, taking into account the hull design, speed and
usage of the boat. Keep in mind that engines today have
become larger, more powerful and heavier than in the past.
SEASTAR PRO FRONT MOUNT
OUTBOARD CYLINDERS
PART
NUMBER
DESCRIPTION
O/B Pro FM PP Cylinder
O/B Pro FM PP Cylinder (Red)
O/B Pro FM PP Cylinder (Silver)
O/B Pro FM PP Cylinder
O/B Pro FM PP Cylinder - Red
O/B Pro FM PP Cylinder - Silver
The SeaStar Pro Front Mount Outboard Cylinders have keyed
support brackets to prevent racking of the cylinder which
gives it a more solid feel and more robust bushings.
SeaStar PRO Outboard cylinders are suited for all those
critical high speed, single powered outboard boats, like Bass,
Flats, combo Race/Ski and other performance orientated
boats capable of speeds in excess of 65mph. All SeaStar PRO
systems require the use of a SeaStar PRO helm and SeaStar
PRO (1500psi) reinforced Kevlar hoses only!
BAYSTAR OUTBOARD CYLINDERS
PART
NUMBER
DESCRIPTION
Outboard Compact Cylinder
Outboard Compact Cylinder - Honda
Outboard Compact - short plate
Outboard Compact Cylinder
This balanced cylinder features a compact design that fits most splashwells.
BayStar allows you to install all of the safety, reliability and comfort of hydraulic
steering onto your boats rated up to MAX. 150HP. Combine this with the
superior design, rigid ISO quality control, the finest materials and precision
manufacturing—BayStar continues the tradition bringing comfort and safety
to boating.
NOTE: Mercury Optimax should use SeaStar cylinders.
Not recommended for use on high performance engines.
STEERING CYLINDERS:
Robust Bushings
Keyed Support Bracket
STEERING - Cylinders
NEW SEALING SYSTEM
• State of the art proprietary seal material
• Similar to Tournament 2
• Excellent resistance to compression set
• 8 hole end gland design for improved serviceability
NEW LOOK
• Updated styling & branding
• Robust barrel
ORB FITTINGS
Adjustable
stainless
steel
O-ring seal (ORB) fittings
Want precise control of engine
trim without taking your
hands off the wheel?
Check out our new
Pro-Trim on page 204 .
