Helms & Helm Fittings (Cont.)

134
®
STEERING - Helms
HELM VISUAL IDENTIFICATION GUIDE:
This is an overview of SeaStar Solutions ROTARY steering helms likely to be encountered.
• Two bolts secure QC cable to helm.
• One bolt holds spent travel tube.
• Cast fnish helms have No FeedBack™ feature.
Kits: SS147xx (4.2 Single Cable),
SS148xx (4.2 Dual Cable),
• Quick connect feature on both the cable
and spent travel tube side.
• Improved NFB feature for smoother release.
Kits: SSX176XX (XTREME™ NFB)
SSX177XX (XTREME™ Tilt NFB)
* only sold in kits to aftermarket
• Collet & hitch pin secure QC cable to helm.
• One bolt holds spent travel tube.
• Safe-T II cast fnish helm has No FeedBack™
feature; HPS gold-finish helm does not.
Kit: SS132xx (Safe-T II Single Cable); HPS Rotary is
sold as components only.
(Single Cable)
(HPS –
gold finish)
(Safe-T II –
cast finish)
(Dual Cable)
SHX97606
NFB™ 4.2
XTREME™ NFB™
NFB™ SAFE-T II
& HPS ROTARY™
SHX7606
