Mechanical Steering Identification Guide (Cont.)

10
®
MECHANICAL STEERING IDENTIFICATION GUIDE
DATES USED
REPLACEMENT
REPLACEMENT
ORIGINAL SYSTEM
&
(NON-POWER-ASSIST
(POWER-ASSIST &
NAME (VERSION)
CABLE COLOR(S)
OUTBOARDS & I/OS)
SMALL INBOARDS)
Teleflex® NFB™
NO-FEEDBACK™
& Morse
®
NFS™ ROTARY Steering Systems To SeaStar Soutions
Morse
®
NFS
To 2001
NFB 4.2 (SS147xx)
(NFB not for power steerng
304415 Cable
Red or Black
or inboard)
XTREME (SSX176XX)
Morse
®
NFS Dual Cable
To 2001
NFB 4.2 Dual Cable (SS148xx)
(NFB not for power steerng
(2) 304415 Cable
Red or Black
or inboard)
NFB 4.2
1990-date
NFB 4.2 (SS147xx)
(NFB not for power steerng
SSC62xx Cable
Black
or inboard)
XTREME (SSX176XX)
SeaStar direct Replacement Cable for these systems is SSC62xx
NFB 4.2 Dual Cable
1990-date
NFB 4.2 Dual Cable (SS148xx)
(NFB not for power steerng
(2) SSC62xx Cable
Black
or inboard)
XTREME (SSX176XX)
SeaStar direct Replacement Cable for these systems is SSC62xx
NFB Safe-T II
1996-date
Sate-T II (SS132xx)
(NFB not for power steerng
SSC62xx Cable
Black
or inboard)
SeaStar Solutions direct Replacement Cable for these systems is SSC62xx
Morse
®
Command 200 Rack To 2001
NFB Rack (SS151xx)
HPS Rack (components) or
300619XX
Red or Black
The Rack (SS141xx)
SeaStar Solutions direct Replacement Cable for these systems is SSC130xx
Morse
®
Rack Dual Cable
To 2001
NFB Pro Rack (SS152xx)
The Rack dual (components)
(2) 300619XX
Red or Black
SeaStar Solutions direct Replacement Cable for these systems is SSC130xx
TR211 (Rack & Pinion)
1973-1975
NFB Rack (SS151xx)
HPS Rack (components) or
SC98XX Cable
Blue
The Rack (SS141xx)
TR188 (Rack & Pinion)
1975-1978
NFB Rack (SS151xx)
HPS Rack (components) or
SC54XX Cable
Brown
The Rack (SS141xx)
TR188 (Rack & Pinion)
1978-1986
NFB Rack (SS151xx)
HPS Rack (components) or
SC105XX Cable
Black
The Rack (SS141xx)
“The Rack” (Rack & Pinion) 1984-1996
NFB Rack (SS151xx)
HPS Rack (components) or
SSC124xx Cable
Black
The Rack (SS141xx)
SeaStar Solutions direct Replacement Cable for these systems is SSC124xx
“The Rack” (Back Mount)
1996-date
NFB Rack (SS151xx)
HPS Rack (components) or
SSC134xx Cable
Black
The Rack (SS141xx)
SeaStar Solutions direct Replacement Cable for these systems is SSC134xx/SSC154xx
“The Rack”
To 1996
NFB Pro Rack (SS152xx)
The Rack dual (components)
Dual Cable System
Black
(2) SSC124xx Cable
SeaStar Solutions direct Replacement Cable for these systems is SSC124xx
“The Rack”
Dual
1996-date
NFB Pro Rack (SS152xx)
The Rack dual (components)
(Back Mount) 2 Cable
Black
SSC135xx Cable
SeaStar Solutions direct Replacement Cable for these systems is SSC135xx
*
**
For footnotes indicated by these symbols, please see page 12.
NOTE: Morse
®
Rack Cable 300620XX cannot be replaced by SSC130xx.
