OIL FILter QuIck-reFerence GuIde
Volvo Diesel -
Continued
Model
Cylinders
Year
Oil Filter
replaces
Crankcase Capacity
recommended Oil
see Notes
18-0032
TAMD122D
6
1989 - 1996
847741
50L / 13.2 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0033
TAMD122P-A, B, C
6
1995 - 2002
478736
50L / 13.2 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0033
TAMD162A / B / C
6
1988 - 1996
478736
73L / 19.3 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0033
TAMD162C-C
6
1999 - 2001
478736
Refer to Owners Manual
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0033
TAMD163A-A / PA
6
1994 - 2001
478736
73L / 19.3 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0033
TAMD165A-A / C-A / P-A
6
2002 - 2005
478736
73L / 19.3 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD40A / B
6
1980 - 1986
423135
10.5L / 11.0 Qt.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD41A/B/D
6
1986 - 1994
423135
10.5L / 11.0 Qt.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD42 B/WJ-A
6
1993 - 2003
423135
10.5L / 11.0 Qt.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD60A/B/C
6
1976 - 1987
423135
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD61A
6
1986 - 1999
847741
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD62A
6
1992 - 1994
847741
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7974
TAMD63LA, 63PA
6
1994 - 2005
3827069
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD63P-A
6
1994 - 2005
847741
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD70B/C
6
1970 - 1978
423135
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD71A
6
1986 - 1994
847741
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-1974
TAMD71B
6
1989 - 2000
3827069
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD72A
6
1991 - 1994
847741
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD72P-A
6
1995 - 1997
847741
27L / 7.1 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD72WJ-A
6
1993 - 1997
847741
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD73P-A/WJ-A
6
1997 - 1999
423135
28L / 7.4 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD74A
6
2000 - 2001
847741
29L / 7.7 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD74A-A / A-B / P-B
6
2000 - 2005
24L / 6.3 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD74C-A, B
6
2000 - 2001
847741
25L / 6.6 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD74L-A, B
6
2000 - 2005
847741
25L / 6.6 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TAMD74P-A, B
6
1998 - 2005
847741
25L / 6.6 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TAMD75P-A
6
1998 - 2005
24L / 6.3 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
THAMD70B/C
6
1972 - 1979
24L / 6.3 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TMD100A
6
1965 - 1983
50L / 13.2 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0033
TMD102A
6
1988 - 2000
478736
50L / 13.2 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7878-1
TMD120A/B
6
1970 - 1983
3517857
50L / 13.2 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TMD41B
6
1989 - 1993
8.5L / 9 Qt.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-7926
TMD41L-A
6
1994 - 1997
10.5L / 11.0 Qt.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
18-0032
TMD70B/C
6
1972 - 1985
847741
20L / 5.28 Gal.
15W-40 VDS-2 or VDS-3 / API CI-4 or higher
Westerbeke
Model
Cylinders
Year
Oil Filter
replaces
Crankcase Capacity
recommended Oil
Propulsion Engines
23-7800
11A One
1
2001 - Current
036918
1.6L / 1.7 Qt.
SAE 10W-30
23-7800
12B Two
2
1983 - 1992
036918
2.8L / 3.0 Qt.
SAE 10W-30
23-7800
12C Two
2
1992 - Current
036918
2.8L / 3.0 Qt.
SAE 10W-30
23-7800
12D Two
2
Current
036918
2.8L / 3.0 Qt.
15W-40 API CI-4, CI-4 Plus, CJ-4
23-7800
20B Two
2
1987 - Current
036918
2.8L / 3.0 Qt.
15W-40 API CI-4, CI-4 Plus, CJ-4
23-7800
W13
2
1980 - 1984
036918
2.8L / 3.0 Qt.
SAE 10W-30
23-7800
W13A
2
1984 - 1988
036918
2.8L / 3.0 Qt.
SAE 10W-30
23-7800
30B Three
3
1987 - Current
036918
2.8L / 3.0 Qt.
15W-40 API CI-4, CI-4 Plus, CJ-4
23-7800
30C Three
3
Current
036918
2.8L / 3.0 Qt.
15W-40 API CI-4, CI-4 Plus, CJ-4
23-7800
35B Three
3
1987 - 2000
036918
4.5L / 4.75 Qt.
SAE 10W-30
23-7800
35C Three
3
2000 - 2002
036918
4.5L / 4.75 Qt.
15W-40 API CI-4, CI-4 Plus, CJ-4
23-7800
35D Three
3
2002 - Current
036918
4.5L / 4.75 Qt.
15W-40 API CI-4, CI-4 Plus, CJ-4
23-7800
35E Three
3
Current
036918
4.5L / 4.75 Qt.
15W-40 API CI-4, CI-4 Plus, CJ-4
23-7800
W18
3
1985 - 1989
036918
3.78L / 4.0 Qt.
SAE 10W-30
23-7800
W21
3
1980 - 1984
036918
3.78L / 4.0 Qt.
SAE 10W-30
23-7800
W21A
3
1984 - 1987
036918
3.78L / 4.0 Qt.
SAE 10W-30
Continued Next Page
All listed oil capacities are approximate amounts only and may or may not include the oil filter capacity.
999
ALWAYS follow proper crankcase drain and fill procedures. Check engine dipstick for proper crankcase oil level.
