Sierra Marine Parts Catalog: Crusader

< Previous Page  Next Page >
Item No
Description
OE No.
Application
1
18-1927
4" RISER
97772
Use with Manifold: 18-1925, 18-1926, 18-1933, & 18-1929; Elbow
Gasket: 18-0309; Mounting Kit: 18-8523
2
NSS
MOUNTING BOLT
N/A
Included in 18-8515 mounting kit.
3
18-0309
ELBOW GASKET
96562
Use with Exhaust Elbow: 18-1927, or 18-1916. Included in 18-8515
mounting kit.
4
--
MOUNTING KIT
N/A
Use with Manifold: 18-1926 w/ alternator bracket
5
18-1928
ELBOW W/ 4" OUTLET
97924
Use with Manifold: 18-1925, 18-1926; Elbow Gasket: 18-0309;
Mounting Kit: 18-8515
6
18-1934
ELBOW W/ 3" OUTLET
98068
Use with Manifold: 18-1925, 18-1926; Elbow Gasket: 18-0309;
Mounting Kit: 18-8515
7
18-1918
ELBOW W/ 2 1/2" INLET
97386
Use with Manifold: 18-1925, 18-1926; Elbow Gasket: 18-0309;
Mounting Kit: 18-8515
8
18-1919
RE-DIRECTION ELBOW
97387
Use with Elbow: 18-1918
W/ 3" OUTLET
9
18-1924
RE-DIRECTION ELBOW
97624
Use with Elbow: 18-1918
W/ 4" OUTLET
10 18-0602
EXHAUST MANIFOLD
N/A
For: "CH" Model Small Block (V8) Chevy 305 CID (5.0L) &
GASKET SET
350 CID (5.7L)
11 18-8540
WASHER & NUT KIT
N/A
Used in mounting kits: 18-8515, 18-8523, & 18-8519
12 18-8515
MOUNTING KIT
N/A
Use with Elbows: 18-1934, 18-1928, 18-1918
13 18-8523
MOUNTING KIT
N/A
Use with Riser: 18-1927
14 18-8519
MOUNTING KIT
N/A
Use with Riser: 18-1916
15 18-8521
MOUNTING KIT
N/A
Use with Manifold: 18-1925 & 18-1926
16 NSS
MOUNTING STUD
N/A
Included in 18-8519 mounting kit
17 NSS
MOUNTING STUD
N/A
Included in 18-8523 mounting kit
18 18-0305
ELBOW GASKET
96108
Use with Exhaust Manifolds: 18-1925 & 18-1926
19 18-1926
MANIFOLD (PORT)
97753, 96121
GM Small Block (V8) 305-351 cu.in. (Models: 220 & 270) (Port);
Use with Manifold Gasket: 18-2949; Mounting Kit: 18-8521
(if manifold has alternator bracket)
20 18-1925
MANIFOLD (STARBOARD)
97752, 96120
GM Small Block (V8) 305-351 cu.in. (Models: 220 & 270)
(Starboard); Use with Manifold Gasket: 18-2949; Mounting
Kit: 18-8521
21 18-2949
MANIFOLD GASKET
96306
Use with Manifolds: 18-1925 & 18-1926
22 NSS
MOUNTING BOLT
N/A
Included in 18-8521 mounting kits
23 18-8112
HOSE FITTING
97296; 97854
90 degree fitting. Thread Size: 1" MPT X 1 1/4"
24 18-4461
HOSE FITTING
N/A
3/4" - 14NPT X 1" Hose (Corrosion Resistant Brass Fitting)
25 18-1917
BLOCK OFF PLATE
97296
Use with Elbow/Riser Gaskets: 18-0309, 18-0305
(STAINLESS)
26 18-1916
8" RISER
97169
Use with Manifolds: 18-1925, 18-1926; Elbow Gasket: 18-0309;
527
Mounting Kit: 18-8519
