Sierra Marine Parts Catalog: Crusader

< Previous Page  Next Page >
Item No
Description
OE No.
Application
1
18-1927
4" RISER
97772
Use with Manifolds: 18-1933, & 18-1929; Elbow Gasket: 18-0309;
Mounting Kit: 18-8523
2
NSS
MOUNTING HARDWARE
N/A
Included in 18-8523 mounting kit.
3
NSS
MOUNTING HARDWARE
N/A
Included in 18-8515 mounting kit.
4
18-0309
ELBOW GASKET
96562
Use with Exhaust Elbow: 18-1928, 18-1934, & 18-1918
5
18-1916
8" RISER
97169
Use with Manifolds: 18-1933, & 18-1929; Elbow Gasket: 18-0309;
Mounting Kit: 18-8519
6
NSS
MOUNTING HARDWARE
N/A
Included in 18-8519 mounting kit.
7
18-8540
WASHER & NUT KIT
N/A
Used in mounting kits: 18-8515, 18-8523, & 18-8519
8
18-8519
MOUNTING KIT
N/A
Use with Riser: 18-1916
9
18-8515
MOUNTING KIT
N/A
Use with Elbows: 18-1934, 18-1928, 18-1918
10 18-8524
MOUNTING KIT
N/A
Use with Manifolds: 18-1929 & 18-1933
11 18-8523
MOUNTING KIT
N/A
Use with Riser: 18-1927
12 NSS
MOUNTING BOLT
N/A
Included in 18-8524 mounting kit.
13 18-0418
MANIFOLD GASKET
96653
Use with Manifold: 18-1929, 18-1933
14 18-0601
EXHAUST MANIFOLD
N/A
For: "CH" Model Big Block (V8) Chevy 454 CID (7.4L); Use with
GASKET SET
Manifolds: 18-1929, & 18-1933
15 18-1917
BLOCK OFF PLATE
97296
Use with Elbow/Riser Gasket: 18-0309, 18-0305
(STAINLESS)
16 18-4461
HOSE FITTING
N/A
3/4" - 14NPT X 1" Hose (Corrosion Resistant Brass Fitting)
17 18-8112
HOSE FITTING
97296; 97854
90 degree fitting. Thread Size: 1" MPT X 1 1/4"
18 18-1929
MANIFOLD (STARBOARD)
97992, 97114
GM Big Block (V8) 454 cu.in. (Models CH350 & 454XL)(Starboard);
Use with Manifold Gasket: 18-0418; Mounting Kit: 18-8524
19 18-1933
MANIFOLD (PORT)
97993, 97115
GM Big Block (V8) 454 cu.in. (Models CH350 & 454XL)(Port); Use
with Manifold Gasket: 18-0418; Mounting Kit: 18-8524
20 18-0305
ELBOW GASKET
96108
Use with Exhaust Manifold: 18-1929, & 18-1933. Included in
18-8515 mounting kit.
21 18-1928
ELBOW W/ 4" OUTLET
97924
Use with Riser: 18-1927 or 18-1916; Elbow Gasket: 18-0309;
Mounting Kit: 18-8515
22 18-1934
ELBOW W/ 3" OUTLET
98068
Use with Riser: 18-1927 or 18-1916; Elbow Gasket: 18-0309;
Mounting Kit: 18-8515
23 18-1918
ELBOW W/ 2 1/2" INLET
97386
Use with Riser: 18-1927 or 18-1916; Elbow Gasket: 18-0309;
Mounting Kit: 18-8515
24 18-1919
RE-DIRECTION
97387
Use with Elbow: 18-1918
ELBOW W/ 3" OUTLET
25 18-1924
RE-DIRECTION
97624
Use with Elbow: 18-1918
ELBOW W/ 4" OUTLET
523
