Sierra Marine Parts Catalog: Yamaha

< Previous Page  Next Page >
Figure
Figure
#
Description
Part #
O.E.M. #
Qty.
#
Description
Part #
O.E.M. #
Qty.
Gearcase 50-75 HP 3 Cyl 1979-2003
47
Trim Tab
18-6097A
6e5-45371-01-00
1
1
Housing, Gearcase
--
6e5-45301-03ek
1
48
Bolt, Trim Tab
--
90105-10M00-00
1
2
plate, Shift rod Cover
--
6e5-45321-00-00
1
49
Gear pinion
--
6e5-45551-02-00
1
3
Bolt, Shift rod Cover
--
97395-06020-00
3
50
Nut, pinion
--
90170-16M01-00
1
4
Washer
--
90209-06M04-00
3
51
Shim (0.10mm)
--
6e5-45567-01-10
Ar
5
o-ring, plate
--
93210-5867-00
1
Shim (0.12mm)
--
6e5-45567-01-12
Ar
6
Shift rod Assembly
--
6e5-44150-01-00
1
Shim (0.15mm)
--
6e5-45567-01-15
Ar
7
Circlip
--
99001-08600-00
1
Shim (0.18mm)
--
6e5-45567-01-18
Ar
8
Bearing, Needle
--
93315-628U9-00
1
Shim (0.30mm)
--
6e5-45567-01-30
Ar
9
Sleeve, Drive Shaft
--
6e5-45536-00-00
1
Shim (0.40mm)
--
6e5-45567-01-40
Ar
10
Drive Shaft (long)
--
6e5-45501-01-00
1
Shim (0.50mm)
--
6e5-45567-01-50
Ar
Drive Shaft (x-long)
--
6e5-45501-21-00
1
52
Bearing, Forward Gear
--
93332-000U7-00
1
11
Key, Impeller
--
90280-04M05-00
1
53
Bearing, Needle
--
93315-425U7-00
2
12
o-ring, Housing
--
93210-54534-00
1
54
Gear, Forward
--
6e5-45560-01-00
1
13
Bearing, Tapered
--
93341-930U0-00
1
55
Shifter
--
6e5-45641-01-00
1
14
Shim (0.10mm)
--
6e5-45587-01-10
Ar
56
Ball, Detent
--
93507-32031-00
1
Shim (0.12mm)
--
6e5-45587-01-12
Ar
57
Ball, Detent
--
93507-32031-00
1
Shim (0.15mm)
--
6e5-45587-01-15
Ar
58
Slide, Shift
--
6e5-45634-01-00
1
Shim (0.18mm)
--
6e5-45587-01-18
Ar
59
Ball, Detent
--
93503-16010-00
1
Shim (0.30mm)
--
6e5-45587-01-30
Ar
60
Ball, Detent
--
93503-16010-00
1
Shim (0.40mm)
--
6e5-45587-01-40
Ar
61
Ball, Detent
--
93511-32027-00
1
Shim (0.50mm)
--
6e5-45587-01-50
Ar
62
Spring, Compression
--
90501-16M37-00
1
15
Bearing, Needle
--
93315-430V5-00
1
63
Ball, Detent
--
93511-32027-00
1
16
Housing, Bearing
--
6e5-45331-0094
1
64
Clutch, Dog
--
6r5-45631-01-00
1
17
Bolt, Bearing Housing
--
97395-08025-00
4
65
Cross pin, Clutch
--
90250-08M07-00
1
18
Washer
--
92990-08600-00
4
66
retainer, Cross pin
--
6e5-45631-01-00
1
19
Seal, Drive Shaft
18-0265
93101-28M16-00
2
67
Shaft, propeller
18-2385
6e5-45611-01-00
1
20
Cover, oil Seal
--
6e5-45344-00-00
1
68
Washer, Thrust
--
90201-30M92-00
1
21
Gasket, Wear plate
18-0244
6e5-44315-A0-00
1
69
Gear, reverse
--
6e5-45571-04-00
1
22
Wear plate
18-3344
6G5-44323-00-00
1
70
Shim (0.10mm)
--
6L6-45577-00-10
Ar
23
Impeller
18-3071
6e5-44352-00-00
1
Shim (0.12mm)
--
6L6-45577-00-12
Ar
24
Insert, Water pump
--
6e5-44322-00-00
1
Shim (0.15mm)
--
6L6-45577-00-15
Ar
25
o-ring, Water pump
18-7485
93210-86M38-00
1
Shim (0.18mm)
--
6L6-45577-00-18
Ar
26
o-ring, Water pump
18-7483
93210-37M67-00
1
Shim (0.30mm)
--
6L6-45577-00-30
Ar
27
pin, Water pump Housing
--
93606-12019-00
2
Shim (0.40mm)
--
6L6-45577-00-40
Ar
28
Housing, Water pump
18-3170
6e5-44311-00-00
1
Shim (0.50mm)
--
6L6-45577-00-50
Ar
29
Damper, Water Seal
--
6e5-44365-00-00
1
71
Washer, Thrust
--
6e5-45576-00-00
1
30
Cover, pump Housing
--
6e5-44312-00-0
1
72
Bearing, reverse Gear
--
93306-208U0-00
1
31
Bolt, Water pump
--
97080-08045-00
4
73
o-ring, Bearing Housing
--
93210-86M39-00
1
32
Washer
--
90209-08M02-00
4
74
Housing, Bearing
--
6e5-45332-00-94
1
33
Nipple, Hose
--
6e5-45378-00-00
1
75
Key, Bearing Housing
--
90282-04010-00
1
34
Drain,plug Lower
18-2374
688-45341-00-00
1
76
Bearing, Needle
--
93315-430U8-00
1
35
Gasket, Drain plug
18-4698
90430-08020-00
1
77
Seal, prop Shaft
18-0266
93101-30M17-00
2
36
Drain plug Upper
--
90340-08M04-00
1
78
Washer, Tab
--
688-45383-02-00
1
37
Gasket, Drain plug
18-4698
90430-08020-00
1
79
Nut, Cover
--
688-45384-00-00
1
38
pin, Locating
--
93608-12M05-00
2
80
Washer, Thrust
--
6e5-45987-01-00
1
39
Cover, Water Inlet (port)
--
688-45214-02-00
1
81
Spacer, prop
18-4274
688-45997-01-00
1
40
Cover, Water Inlet (Stbd)
--
688-45215-02-00
1
82
Washer, prop
--
92990-18200-00
1
41
Screw, Water Inlet
--
90142-05M03-00
1
83
Nut, prop
18-3726
90171-18M04-00
1
42
Nut, Water Inlet
--
90185-05002-00
1
84
pin, Cotter
18-3735
91490-40030-00
1
43
Bolt
--
97395-10070-00
1
85
Gear Housing Seal Kit
18-2796
6e5-W0001-51-00
1
44
Bolt
--
97395-10070-00
1
86
Water pump repair Kit
18-3372
6e5-W0078-00-00
1
45
Washer
--
92990-10100-00
1
46
Washer
--
92990-10100-00
1
Ar
As required
