Special Model
Variation Code
Horse-
Trim & Tilt/Starting
Shaft
Model
(Used on 25HP
Model Description
power
Method
Length
Control Method
Year
engines)
B = Inshore series
example:  T = power tilt or trim/tilt  S = 15"
r = remote control  N = 1984  2 = 3 Cyl. 1997
C = C series model
6
(1984-1990)
L = 20"
H = Tiller handle
K = 1985  3 = 3 Cyl.
CV = C series
9.9
p = power tilt with
X = 25"
J = Jet drive unit
J = 1986
D = Twin rotating propellers
200
electric start
U = 30"
H = 1987
DX = Twin rotating propellers oX66 eFI
250
e = electric start
G = 1988
e = enduro series model
(1984-1990)
F = 1989
F = Four stroke engine model
M = Manual tilt with
D = 1990
LF = Left hand four stroke
manual start
p = 1991
L = Left hand engine model
Q = 1992
LX = Left hand oX66 eFI
r = 1993
LZ = Left hand HpDI
S = 1994
p = pro series model
T = 1995
pX = pro series oX66 eFI
U = 1996
S = Saltwater series model
V = 1997
SX = Saltwater series oX66 eFI
W= 1998
T = Four stroke engine with high thrust
X = 1999
V = V max series model
Y = 2000
VX = V max oX66 eFI
Z = 2001
VZ = V max HpDI
A = 2002
Z = HpDI series
B = 2003
C = 2004
D = 2005
Starting in April 2005 (2006 Model Year and newer) Yamaha no longer designated model years at the end of the model number identification.
Beginning at this time any subsequent "new model" will have a letter designation between the Horsepower and the Control / Tilt Method.
Example:
VZ300TLR = New model after April 2005.
VZ300BTLR = Newest Model and direct replacement for previous models.
VZ300TLRD = 2005
EXAMPLE: SX150TLrY - Saltwater eFI, 150 Hp, Trim & Tilt w/electric start, 20", remote control, 2000 model
b
b
18-5131
CDI
18-5130
Replaces: 695-85540-11,
CDI
695-85540-12
Replaces: 688-85540-16
Fits: 9.9(1984-95), 15(1984-95),
Fits: 90(1988-91), C75(1994-96), C85(1991-96),
C25(1992-97), CV25(1990)
CV85(1989-90), E75(1995-96)
b
18-5132
18-5110
18-5111
CDI
IGNITION COIL
IGNITION COIL
Replaces: 63V-85540-01
Replaces: 6E5-85570-11-00
Replaces: 697-85570-11-00
For: 115 (4 cyl.) 1985-91
For: 55 (2 cyl.) 1989-94
Fits: 9.9(1999-09), 15(1999-09)
b
b
18-5195
18-5128
COIL, IGNITION
18-5183
IGNITION COIL
18-5112
Replaces: 689-81311-40
COIL, CHARGE
Replaces: 6R3-85570-01-00
IGNITION COIL
Fits: 25(1984-87), 30(1984-86),
Replaces: 63V-85520-00,
For: 115/130/150HP (1994-04) 175HP
Replaces: 6E7-85570-19-00,
C30(1991-92), C40(1994-97),
(1994-95, 1997-98, 2000) 200HP (1994-98)
63V-85520-01
680-85570-09-00
225HP (1997) B115HP 1998-99) C115HP
CV30(1989-90), CV40(1990)
410
For: 9.9/15 1988-93
Fits: 9.9(1996-03)., 15(1996-03)
(1997-98) for late model V4 & V6
