Sierra Marine Parts Catalog: Mercury Mariner

< Previous Page  Next Page >
Figure
#
Description
Part #
O.E.M. #
Qty.
34
Water pump Base
18-3416
46-96146A6
1
35
Gasket
18-2914
27-856081
1
36
Face plate
18-3117
32435
1
37
Gasket
18-2915
27-856091
1
38
Key
~
28-56654
1
39
Impeller
18-3017
47-899842
1
40
Insert
18-3114
48752
1
41
Water pump Body
18-3116
43-96148A1
1
42
Washer
18-4275
12-29245
3
43
Nut
18-3722
11-20361
2
44
Seal
18-3110
26-38970
1
45
Guide Sleeve
18-3109
23-29804
1
46
Washer
18-4270
12-36001
1
47
Nut
18-3722
11-45592
1
48
Slinger
18-7426
25-30271
1
49
Washer
18-4275
12-29245
3
50
Screw
~
10-96411
1
Figure
51
Trim Tab
18-6011
3164A1
1
#
Description
Part #
O.E.M. #
Qty.
52
Screw
~
10-66024
1
1
Gear Housing
~
1647-9148A65
1
53
Shift Cam
~
78956
1
2
Water Insert (Starboard)
~
66885
1
54
Nut
18-3721
11-34933
1
Water Insert (port)
~
66884
1
55
Washer
~
12-45176
2
3
Screw
18-3197
10-76156
1
56
Screw
~
10-65210
1
4
Drain Screw
18-2375
22-67892A1
1
57
Cam Follower
~
89594A1
1
5
Washer
18-2945
12-19183
2
58
Actuator rod
~
79911 1
1
6
Nut
18-2344
11-45812
1
59
Locating pin
~
17-78906
1
7
Dowel pin
~
17-43044
2
60
Spring
~
24-749910
2
8
Vent Screw
18-2244
10-79953
1
61
Washer
~
12-78910
1
9
Stud
~
16-78638
1
62
Shim Assembly
18-2285
15-47397A1
Ar
10
Stud
~
16-56297
1
63
Bearing
18-1166
31-78172A1
1
11
Stud
~
16-30667
2
64
Forward Gear
~
43-78082A3
1
12
Stud
~
16-579201
2
65
roller Bearing
18-1122
31-73363
2
13
roller Bearing
~
31-35934A1
1
66
Clutch
~
52-823174
1
14
pinion Gear
~
43-780811
1
67
Detent pin
~
17-78909
2
15
pinion Nut
18-3719
11-35921
1
68
Cross pin
~
17-78905
1
16
Speedometer Tube
~
22-85822A10
1
69
retaining Spring
~
24-78962
2
17
Shift Shaft
~
78902 2
1
70
prop Shaft
18-2239
44-94148
1
18
e-Clip
18-4295
53-29641
1
71
reverse Gear
~
43-85462
1
19
o-ring
18-7153
25-21836
1
72
Thrust ring
~
68100 1
1
20
Shift Shaft Bushing
18-2155
23-77631A2
1
73
Ball Bearing
18-1155
30-88957
1
21
Seal
18-2054
26-816461
1
74
o-ring
18-7159
25-31534
1
22
rubber Washer
18-2316
12-77674
1
75
Bearing Carrier
18-1567
43567T1
1
23
Sleeve
~
23-98621
1
76
Key
~
28-30281
1
24
Shim Assembly
18-2295
15-57007A1
Ar
77
roller Bearing
18-1158
31-30956
1
25
roller Bearing
18-1164
31-53079A1
1
78
Seal (Inner)
18-2002
26-76868
1
26
roller Bearing
18-1164
31-53079A1
1
79
Seal (outer)
18-2053
26-70081
1
27
Drive Shaft Assembly
~
45-98682A1
1
80
Tab Washer
18-2299
14-79447
1
28
Spring
~
24-34576
1
81
Cover Nut
18-3751
79448
1
29
pin
~
17-30545
1
82
Thrust Hub
18-4220
13171
1
30
Gasket
18-2826
27-856101
1
83
Spline Washer
18-3714
12-31211A2
1
31
o-ring
18-7162
25-33145
1
84
Tab Washer
18-3200
14-31210
1
32
Seal
18-2014
26-89238
1
85
prop Nut
18-3700
11-52707
1
33
Seal
18-2013
26-16977
1
Ar
As required
373
