Sierra Marine Parts Catalog: Johnson Evinrude

< Previous Page  Next Page >
Figure
Figure
#
Description
Part #
O.E.M. #
Qty.
#
Description
Part #
O.E.M. #
Qty.
Gearcase 50-75 HP 3 Cyl 1979-2003
43
pin, Shift Lever
--
328825
1
1
Housing Gearcase
--
438050
1
44
Shift Shaft
18-3763
322941
1
2
Shift rod (long)
--
324407
1
45
Cradler, Shifter
18-3766
334163
1
2
Shift rod (x-long)
--
324408
1
46
Shift Lever
18-3762
322938
1
3
Cover & Shift rod
--
435482
1
47
Thrust Washer, Forwardd Gear
18-0199
327669
1
4
Screw, Cover
18-3369
302325
6
48
Thrust Bearing, Forward Gear
18-1370
389042
1
5
o-ring, Shift rod
18-7137
318372
1
49
Gear Set, Forward & pinion
NSS
435020
1
6
Gasket, Shift Housing
18-0110
324670
1
50
Sliding Clutch
18-2216
337774
1
7
Magnetic Drain Screw
18-2378
318544
2
51
pin, Clutch Dog
18-1714
313448
1
8
o-rings, plugs
18-7145
333572
2
52
retaining Spring
18-2399
324369
1
9
Screw
--
324852
1
53
propeller Shaft
18-2187
395209
1
10
o-ring
18-7120
307853
1
54
Gear, reverse
NSS
910994
1
11
Screw,Gearcase to housing
--
320741
5
55
Thrust Bearing, reverse Gear
18-1366
382408
1
12
Screen,Water intake
--
321123
1
56
Thrust Washer, reverse Gear
18-0195
314731
1
13
Anode
18-6024
393023
1
57
retainer plate/Bearing Housing
--
321174
1
14
Trim Tab
--
327640
1
58
retaining rings
--
321171
2
15
Screw,Trim tab
--
313715
1
59
o-ring , Bearing Housing
18-7133
305123
1
16
oil Seal, Upper
18-2061
329922
1
60
Carrier Bearing (Fore)
18-1351
382407
1
17
oil Seal, Lower
18-2062
329923
1
61
Bearing Housing
--
397094
1
18
Screw,Housing to gearcase
--
316534
4
62
Screw, retainer
18-2377
316563
4
19
Bearing Housing
--
438963
1
63
o-ring
18-7109
317178
1
20
o-ring Bearing Housing
18-7130
314728
1
64
roller Bearing (Aft)
18-1158
387247
1
21
Shim .003
18-2229
323362
Ar
65
oil Seals, prop Shaft
18-2002
320862
2
21
Shim .004
18-2230
323361
Ar
66
Thrust Washer
18-4223
333592
1
21
Shim .005
18-2231
314745
Ar
68
propeller
--
various
1
22
Thrust Washer, pinion
18-0200
327656
1
69
Spacer, prop Nut
18-4231
320570
1
23
Thrust Bearing, pinion
18-1365
387665
1
70
Nut, propeller
18-3708-1
398042
1
24
Drive Shaft (long)
see app chart
435755
1
71
Cotter pin, prop Nut
18-3741
306394
1
24
Drive Shaft (x-long)
see app chart
435756
1
72
Gear Housing Seal Kit
18-2623
396353
1
25
Bearing, pinion
18-1117
387817
1
73
Water pump repair Kit
26
Nut, pinion
18-3719
314730
1
(w/housing)
18-3392
434421
1
27
Cup & plate Assembly
18-3346
330380
1
74
Grommet
18-2706
321008
1
28
Key, Impeller
18-3299
331107
1
75
Spacer,Shift rod
--
321122
1
29
Seal, Impeller Housing
18-7963
331353
1
76
Gasket,Impeller housing plate
18-2557
324701
1
30
Impeller
18-3059
397131
1
77
o-ring, Drive Shaft
18-7158
310585
1
31
Cup & plate Assembly
18-3346
330379
1
78
Screw,Cover to impeller
18-3135
306643
2
32
o-ring, Drive Shaft
18-7158
310585
1
79
o-ring,Driveshaft to crankcase
18-7158
310585
1
33
Housing, Water pump
18-3130
395040
1
34
Grommet, Water Tube
18-2703
314008
1
35
pump cover
--
321159
1
36
Screw,Impeller housing
18-3136
323626
4
37
Grommet
18-2704
320943
1
38
Bearing Housing Assembly
18-3767
389455
1
39
Ball, Detent
18-1501
160084
1
40
Spring, Detent
18-1502
911962
1
41
pin, Housing
18-3765
331880
1
42
Detent, Shifter
--
323946
1
275
Ar
As required
