Sierra Marine Parts Catalog: Johnson Evinrude

< Previous Page  Next Page >
Figure
Figure
#
Description
Part #
O.E.M. #
Qty.
#
Description
Part #
O.E.M. #
Qty.
Gearcase 50-75 HP 3 Cyl 1979-2003
47
Spring Clutch
18-2398
320311
1
1
Housing, Gearcase
--
435275
1
48
Clutch Sliding
18-2308
332491
1
2
Trim Tab
--
340539
1
49
pin, Clutch Cross
--
320310
1
3
Washer, Anode
--
330266
1
50
Spring Shifter
--
332484
1
4
Bolt, Anode retaining
--
330930
1
51
Gear Set, Forward & pinion
18-2310
397627
1
5
Washer
--
330265
1
52
Thrust Bearing, Forward Gear
18-1364
397538
1
6
Bolt
--
313697
1
53
Thrust Washer, Forward Gear
18-0197
333725
1
7
Washer
--
330266
4
54
Bearing Forward, outer
18-1351
382407
1
8
Bolt
--
305282
4
55
Thrust Bearing, Forward Gear
18-1369
432264
1
10
o-ring
18-4253-9
336982
1
56
propeller Shaft
18-2288
439138
1
11
Drain plug, Upper
18-1236
309243
1
57
Shaft, Shift Dog
--
332503
1
12
Seal
18-7475
332584
1
58
Ball, Detent
18-2243
316506
3
13
retaining Screw
--
324852
1
59
Nut, pinion
--
313339
1
14
o-ring Screw
18-7109
317178
1
60
Gear Set, Forward & pinion
18-2310
397627
1
15
Screw, Shift Lever
--
333770
1
61
Bearing pinion
18-1356
382343
1
16
Gasket, Drain plug
18-4248
311598
1
62
Driveshaft (std)
--
433066
1
17
Drain Fill plug, Lower
18-2378
318544
1
Driveshaft (long)
18-1721
433067
1
18
Screen, Water Intake
--
332494
2
63
Washer, Thrust
18-0201
333771
2
19
Bolt, Inlet Screen retainer
--
325539
2
64
Thrust Bearing, Driveshaft
18-1368
398901
1
20
Cradle, Shifter
--
332507
1
65
Shim (.003)
--
313273
Ar
21
Lever, Shift
--
332492
1
Shim (.004)
--
313274
Ar
22
Connector, Shift rod
--
332508
1
Shim (.005)
--
313275
Ar
23
pin, Connector
--
302504
1
Shim (.006)
--
313276
Ar
24
Cotter pin
--
306376
1
Shim (.007)
--
313277
Ar
25
o-ring, Shift rod Cover
--
338522
1
66
o-ring, Gear Housing
18-7173
310327
1
26
Cover, Shift rod
18-1729
434588
1
67
Cap, Upper Driveshaft,
27
Bolt, Shift rod Cover
--
316037
2
retaining
--
435274
1
28
o-ring, Shift rod
18-7137
318372
1
68
Bolt, Driveshaft retaining
18-1279
317624
3
29
Bushing, Shift rod
--
333780
1
69
Seal Lower
18-2059
321466
1
30
Shift rod (std.)
--
332509
1
70
Seal Upper
18-2064
332205
1
Shift rod (long)
--
332510
1
71
Gasket, Impeller
18-2709
336530
1
31
Nut, prop
18-3705
314503
1
72
plate, Impeller
NSS
341038
1
32
pin, Cotter
18-3742
314502
1
73
Key, Impeller
18-3138
334897
1
33
Spacer, prop
18-4228
315810
1
74
Impeller
18-3104
432941
1
34
Washer, prop Thrust
18-4230
320305
1
75
Skirting, Insert
NSS
324980
1
35
Anode, Bearing Housing
--
398873
1
76
plate, Insert Top
18-3126
321940
1
36
Bolt, Anode retaining
--
328694
2
77
Seal, rubber
18-7481
324981
1
37
oil Seals, prop Shaft
18-2060
321467
2
78
Housing, W/p
18-3129
438544
1
38
Bearing, Needle
18-1355
386765
1
79
Bolt, Water pump Housing
18-3369
302325
4
39
Bearing Carrier Assembly
18-1708
432276
1
80
Gear Housing Seal Kit
18-2694
433550
1
40
Tabs, retaining
18-1343
332495
2
81
Water pump repair Kit
18-3394
433548
1
41
Bolt, Carrier retaining
--
328744
2
42
o-ring, Bearing Housing
18-7172
553126
1
43
Bearing, Needle
18-1354
386764
1
44
Thrust Washer, reverse Gear
18-0196
332514
1
45
Thrust Bearing, reverse Gear
18-1363
397537
1
46
Gear, reverse
18-2309
332489
1
269
Ar
As required
NSS
Not Sold Seperate
