Sierra Marine Parts Catalog: Johnson Evinrude

< Previous Page  Next Page >
Figure
Figure
#
Description
Part #
O.E.M. #
Qty.
#
Description
Part #
O.E.M. #
Qty.
Gearcase 50-75 HP 3 Cyl 1979-2003
46
Screw, Screen retaining
--
325539
2
1
Gear Housing
--
434030
1
47
Washer, Thrust
--
327716
1
2
Tube Water
--
395339
1
48
Bearing, Thrust
--
388027
1
3
Grommet
18-3329
302497
1
49
Washer, Thrust
--
330441
1
4
Housing, Water pump
18-3367
393632
1
50
Gear, pinion
18-1288
328313
1
5
Tube, extension
--
326692
1
51
Bearing, Forward Gear
--
386186
1
6
o-ring
18-7105
311338
2
52
Gear, Forward
18-1287
392475
1
7
Bolt, Water pump Housing
--
328725
6
53
Clutch Sliding
18-1290
337020
1
8
o-ring
18-7146
554545
1
54
Spring, Detent
--
327070
1
9
Insert, Water pump Housing
18-3358
328751
1
55
Ball, Detent
18-2243
316506
2
10
Impeller
18-3051
395289
1
56
Lever Shifter
--
337019
1
11
Key, Water pump
18-3295
344470
1
57
Cradle, Sliding Clutch
--
438311
1
12
Bushing
--
328754
1
58
pin, Shift
--
302504
1
13
o-ring
18-7100
301877
1
59
Cotterpin, Shift Lever
--
303049
1
14
Seal, Spaghetti
18-2539
328753
1
60
Yoke & Connector Assy.
--
390023
1
15
plate, Wear
18-3359
328753
1
61
Shaft, propeller
--
439143
1
16
Gasket, Water pump
18-0124
325537
1
62
Gear, reverse
18-1289
327655
1
17
Drive Shaft (15")
--
341635
1
63
Bushing, reverse Gear
--
319635
1
Drive Shaft (20")
--
341636
1
64
plate, retainer
--
319746
1
18
Seal Drive Shaft (upper)
18-2065
332261
1
65
ring, retaining
--
319747
1
19
Seal Drive Shaft (lower)
18-2033
321938
1
66
Washer, Forward Gear Thrust
--
319684
1
20
Bearing, Driveshaft
--
386473
1
67
Bearing, propshaft
--
437288
2
21
Collar, Housing
--
322018
1
68
o-ring
18-2026
338518
1
22
Bearing, pinion
--
437288
2
69
Seal
18-7475
332584
2
23
Nut, Housing
--
306422
1
70
Bolt, Carrier retaining
--
319743
2
24
Washer, Locking
--
301250
1
71
Carrier, Bearing
--
433428
1
25
Bushing, Housing Alignment
--
319785
1
72
Seal, propshaft
18-2026
321453
2
26
Stud
--
320173
1
73
Spacer, prop
18-4232
335420
1
27
Connector, Shift
--
325624
1
74
prop Nut & Spacer
18-3707
319891
1
28
Shift rod
--
331479
1
75
Cotter pin, prop Nut
18-3743
320785
1
29
Keeper, Nylon Shift
--
325625
2
76
Gear Housing Seal Kit
18-2658
396351
1
30
Nut, Shiftshaft retaining
--
331465
1
77
Water pump Kit
18-3382
393639
1
31
Bushing
--
326361
1
32
o-ring
18-7180
303347
1
33
o-ring
18-7100
301877
1
34
Washer, expanding
18-0189
321738
1
35
Anode Kit
--
434029
1
36
Lockwasher
--
304454
1
37
Bolt, Anode reataining
--
333677
1
38
Bolt, Trim Tab retaining
--
329217
1
39
Trim Tab
--
336203
1
40
Bolt, Housing retaining
--
328333
4
41
Gasket, Drain plug
18-4248
311598
2
42
plug, Drain
18-2387
307551
2
43
Seal
18-7475
332584
1
44
pin, Shift Lever pivot
--
308376
1
45
Screen, Water Inlet
--
336202,
2
267
336206
