Sierra Marine Parts Catalog: Johnson Evinrude

< Previous Page  Next Page >
-- CONTAINS --
Part #
Desc.
O.E. #
Qty.
18-0963
Intake Manifold GasketTwin
335633
1
18-0850
Fuel Pump Mtg. Gasket
303615
1
18-0118
Carburetor Gasket
325092
2
18-0983
Carburetor to Airbox
321497
1
18-3802
Head Gasket
327795, 335359
1
18-0941
Water Jacket Cover Gasket
315538
1
18-0157
Air Box Split Gasket
330698
1
18-0128
Powerhead Mounting Gasket
326468
1
18-0136
Powerhead Mounting Gasket
328283
1
18-1224
Exhaust Cover Gasket
315869
1
18-4318
POWERHEAD GASKET SET
18-1218
Exhaust Cover Gasket
315868
1
Replaces: 390076
18-0182
Seal
310058
1
-- CONTAINS --
Part #
Desc.
O.E. #
Qty.
18-0118
Carburetor Gasket
325092
3
18-0989
Air Silencer Gasket
321794
1
18-0975
Carb to Silencer Gasket
333008
1
18-3836
Head Gasket
329836
1
18-1202
Thermostat Cover Gasket
329830
1
18-1205
Adapter Gasket
329828
1
18-1207
Exhaust Manifold Gasket
329833
1
18-4321
18-1212
Intake Manifold Gasket
326926
1
POWERHEAD GASKET SET
18-1219
Grommet
320880
1
Replaces: 398047
18-1221
Retainer
330273
1
-- CONTAINS --
Part #
Desc.
O.E. #
Qty.
18-0987
Throttle Body to Manifold Gasket
332319
2
18-0142
Intake Manifold Gasket
328622
1
18-2074
Seal
322575, 339620
1
18-2075
Seal
332942
1
18-0130
Reed Box Gasket
332266
4
18-7418
O-Ring
326741
4
18-0155
Rectifier Mtg. Gasket
330412
1
18-3866
Head Gasket
328623, 340115
2
18-0138
Adapter to Powerhead Gasket
328590
1
18-0144
Reed Box Gasket
328626
4
18-4322
Retainer
330273
2
18-1221
POWERHEAD GASKET SET
Replaces: 432570
18-1219
Grommet
320880
2
18-1222
Thermostat Gasket
394408
2
252
APPLICATION BEGINS ON PAGE 256
