Sierra Marine Parts Catalog: Accessories Miscellaneous

< Previous Page  Next Page >
18-9854
18-9856
DRIvE SHAFT ADAPTER
18-9855
DRIvE GEAR SHIMMING TOOL
DRIvEN GEAR SHIMMING TOOL
Replaces: Mercury Marine 91-56775T
Replaces: Mercury Marine 91-60526T
Replaces: Mercury Marine 91-60523
Description: Provides a wrench surface to
turn the drive shaft on MC-I, R-MR, Alpha
Description: Measures upper drive gear
Description: Measures upper drive gear
One, Alpha One/Gen II drive units and
clearance on MC-I, R-MR, Alpha One,
clearance on MC-I, R-MR, Alpha One and
outboards.
Alpha One/Gen II drive units.
Alpha One/Gen II drive units.
18-9858
18-9857
18-9868
BEARING CARRIER
PINION NUT ADAPTER
DRIvE SHAFT ADAPTER
RETAINER WRENCH
Replaces: Mercury Marine 91-61067A3
Replaces: Mercury Marine 91-61077
Replaces: Mercury Marine 91-61069T
Description: Holds pinion nut when
Description: Provides a wrench surface
Description: Removes and installs bearing
removing pinion gear and drive shaft on
to turn the propeller shaft on MC-I, R-MR,
carrier retainer nuts on Bravo One and
MC-I, R-MR, Alpha One drive units and
Alpha One, Alpha One/Gen II, Bravo One
Two, MC-I, R-MR, Alpha One, Alpha One/
outboards.
and TRS drive units.
Gen II, TRS drive units and outboards.
18-9859
PULLER
18-9860
18-9861
Replaces: Mercury Marine 91-63616
BEARING DRIvER
HINGE PIN TOOL
Replaces: Mercury Marine 91-63638T
Description: Removes upper swivel shaft
Replaces: Mercury Marine 91-78310
on MC-I, R-MR, Alpha One, Alpha One/
Description: Removes and installs lower
Description: Removes and installs hinge
Gen II, Bravo One,Two and Three and
drive shaft pinion bearing on TR and Bravo
pins from all Mercury Marine drive units.
Blackhawk gimbal rings.
One and Two drive units.
18-9870
18-9869
18-9871
SLEEvE INSTALLATION TOOL
UPPER DRIvE SHAFT
SLEEvE REMOvAL TOOL
Replaces: Mercury Marine 91-818162
HOUSING SEAL DRIvER
Replaces: Mercury Marine 91-818169T
Description: Installs the aluminum sleeve
Replaces: Mercury Marine 91-817570T
Description: Removes the aluminum sleeve
in the u-joint bellows of all Bravo, Alpha
Description: Installs seals in Alpha One/
from the u-joint bellows of all Bravo, Alpha
One/Gen II, Blackhawk drive units and
Gen II upper drive shaft housing.
One/Gen II and Blackhawk drive units.
outboards.
18-9866
DIAL INDICATOR HOLDING TOOL
18-9863
18-9872
Replaces: Mercury Marine 91-89897
BEARING DRIvER
PUMP ALIGNMENT TOOLS
Description: Secures dial indicator to gear
Replaces: Mercury Marine 91-89865
Replaces: Mercury Marine 91-821571A1
housing when checking backlash on MC-I,
Description: Installs bearing carrier seals
Description: Aligns Alpha One/Gen II water
R-MR, Alpha One, TR, TRS drive units and
on Bravo One and Two drive units.
pump during installation.
outboards.
171
FOR COMPLETE TOOL ASSORTMENT SEE PAGE 173
