SHIELDS EPDM ELBOWS - 90
Part Number
ID
mm
A
mm
B
mm
C
mm
D
mm
R
mm
T
mm
2.0
3.5
3.5
1.5
1.5
2.0
.25
16-290-2000
51
88.9
89
38
38
51
6
2.5
4.0
4.0
1.5
1.5
2.5
.25
16-290-2120
64
102
102
38
38
64
6
3.0
5.45
5.25
1.5
1.5
3.75
.25
16-290-3000
76
138
133
38
38
95
6
3.5
5.5
5.5
1.5
1.5
4.0
.25
16-290-3120
89
140
140
38
38
102
6
4.0
5.75
5.75
1.25
1.25
4.5
.25
16-290-4000
102
146
146
32
32
114
6
4.5
5.5
5.5
2.0
2.0
3.5
.25
16-290-4120
114
140
140
51
51
89
6
5.0
6.12
6.12
1.75
1.75
4.74
.25
16-290-5000
127
155
155
45
45
120
6
6.0
6.75
6.75
1.75
1.75
5.0
.25
16-290-6000
152
171
171
45
45
127
6
8.0
8.5
8.5
2.0
2.0
6.5
.37
16-290-8000
203
216
216
51
51
165
9
SHIELDS EPDM ELBOWS
- 90 REDUCING ELBOW
Part Number
ID1
mm
ID2
mm
A
mm
B
mm
C
mm
D
mm
R
mm
T
mm
5.50
4.00
8.00
3.63
1.25
2.25
.20
16-291-500x400
140
102
203
92
32
57
5
6.00
5.00
5.00
5.00
1.50
1.50
3.50
.25
16-291-600x500
152
127
127
127
38
38
89
6
Also available with series 720 T-bolt clamps. Order part number with "Kit" Suffix.
