Sierra Marine Parts Catalog

< Previous Page  Next Page >
SHIELDS EPDM COUPLERS
- SINGLE & DOUBLE HUMP
100% High temperature EPDM rubber. Maximum operating temperature 250 F (120 C).
Part Number
A
mm
B
mm
C
mm
D
mm
E
mm
F
mm
G
mm
T
mm
3.00
3.00
5.25
2.62
1.87
1.87
4.50
.25
16-220-3000
76
76
133
67
48
48
114
6
3.50
3.50
5.25
3.00
2.25
2.25
5.00
.25
16-220-3120
89
89
133
76
57
57
127
6
4.00
3.00
5.25
2.00
2.00
3.00
5.25
.25
16-221-400x300
102
76
133
51
51
76
133
6
4.00
4.00
5.25
2.63
2.00
2.00
5.25
.25
16-220-4000
102
102
133
67
51
51
133
6
4.50
4.50
6.00
3.00
2.25
2.25
6.00
.25
16-220-4120
114
114
152
76
57
57
152
6
5.00
4.00
6.00
3.00
2.12
1.81
6.25
.25
16-221-500x400
127
102
152
76
54
46
159
6
5.00
5.00
6.00
3.00
2.25
2.25
6.10
.25
16-220-5000
127
127
152
76
57
57
155
6
6.00
5.00
6.00
3.00
2.13
1.88
7.50
.25
16-221-600x500
152
127
152
76
54
48
191
6
6.00
6.00
6.00
3.00
2.25
2.25
7.38
.25
16-220-6000
152
152
152
76
57
57
188
6
8.00
6.00
6.00
1.75
1.95
3.00
9.50
.25
16-221-800x600
203
152
152
45
50
76
241
6
8.00
8.00
8.00
4.00
3.00
3.00
10.37
.31
16-220-8000
203
203
203
102
76
76
263
8
10.00
8.00
6.00
3.00
2.00
1.75
11.50
.25
16-221-1000x800
254
203
152
76
51
45
292
6
10.00
10.00
6.00
3.00
2.00
2.00
11.50
.25
16-220-10000
254
254
152
76
51
51
292
6
SHIELDS EPDM ELBOWS - 45
Part Number
ID
mm
A
mm
B
mm
C
mm
D
mm
R
mm
T
mm
3.0
5.5
5.5
1.6
1.6
3.75
.25
16-245-3000
76
140
140
41
41
95
6
3.5
5.5
5.5
2.0
2.0
4.0
.25
16-245-3120
89
140
140
51
51
102
6
4.0
5.5
5.5
1.46
1.46
4.25
.25
16-245-4000
102
140
140
37
37
108
6
4.5
5.06
5.06
1.5
1.5
3.5
.25
16-245-4120
114
129
129
38
38
89
6
5.0
5.5
5.5
1.36
1.36
4.5
.25
16-245-5000
127
140
140
35
35
114
6
6.0
6.5
6.5
1.74
1.74
5.0
.25
16-245-6000
152
165
165
44
44
127
6
8.0
8.06
8.06
2.0
2.0
6.5
.37
16-245-8000
203
205
205
51
51
165
9
10.0
10.5
10.5
2.25
2.75
8.5
.37
16-245-10000
254
267
267
57
70
216
9
