SHIELDS SILICONE ELBOWS - 45
Part Number
ID
mm
A
mm
B
mm
C
mm
D
mm
R
mm
T
mm
3.0
5.5
5.5
1.6
1.6
3.75
.25
16-245S3000
76
140
140
41
41
95
6
4.0
5.5
5.5
1.46
1.46
4.25
.25
16-245S4000
102
140
140
37
37
108
6
5.0
5.5
5.5
1.36
1.36
4.5
.25
16-245S5000
127
140
140
35
35
114
6
6.0
6.5
6.5
1.74
1.74
5.0
.25
16-245S6000
152
165
165
44
44
127
6
SHIELDS SILICONE ELBOWS - 90
Part Number
ID
mm
A
mm
B
mm
C
mm
D
mm
R
mm
T
mm
2.0
3.5
3.5
1.5
1.5
2.0
.25
16-290S2000
51
88.9
89
38
38
51
6
3.0
5.45
5.25
1.5
1.5
3.75
.25
16-290S3000
76
138
133
38
38
95
6
4.0
5.75
5.75
1.25
1.25
4.5
.25
16-290S4000
102
146
146
32
32
114
6
5.0
6.12
6.12
1.75
1.75
4.74
.25
16-290S5000
127
155
155
45
45
120
6
6.0
6.75
6.75
1.75
1.75
5.0
.25
16-290S6000
152
171
171
45
45
127
6
8.0
8.5
8.5
2.0
2.0
6.5
.37
16-290S8000
203
216
216
51
51
165
9
