FUEL FILTERS
4.25"
108.0 mm
4.25"
3.5"
4.25"
108.0 mm
88.9 mm
108.0 mm
AquaVueTM drain
bowl style filters with
see through plastic
6.25"
9.75"
6.5"
158.8 mm
247.7 mm
165.1 mm
bowl or fire resistant
8"
203.2 mm
metal
bowl for below
Standard
deck installation.
Compact
30 GPH for up to 115 HP motors
Extra Capacity
Drain Bowl
(Use with N-187774S head.)
Part #
Description
Rating
18-7928
Filter w/ AquaVueTM bowl
10 Micron
18-7929
Filter w/ Metal bowl
10 Micron
18-7866
Extra Capacity - 6"
10 Micron
18-7944
Short - 3.88"
10 Micron
18-7945
Long - 4.35"
10 Micron
18-7844
Short - 3.88"
21 Micron
Long - 4.35"
21 Micron
18-7845
18-7865
Compact Filter
10 Micron
Filters available in standard packs of 12.
FILTER FEATURES
Ethanol blended fuel absorbs more water and loosens more particulants than regular fuels. Proper filtration is
required for every horsepower engine. Sierra fuel water separators remove over 98.8% of emulsified water from your
gasoline. Sierra's 10 micron filters are over 90% efficient at removing particles as small as 10 micron. All filters
flow at 90 GPH to feed even the hungriest motor. Sierra 10 micron filters are recommended to prevent damage
to sensitive inboard and outboard fuel injection systems.
CUSTOM FUEL LINE ASSEMBLIES
PRIMER BULBS
Sierra can fabricate custom assemblies for
Sierra is a leading supplier of primer
OEM applications.
bulbs to the marine aftermarket.
Any combination of hose
Our bulbs are molded in house. We
and fittings is possible.
use double check valves with viton
Use type A hose to the splash
balls and stainless steel springs.
well and type B hose to the engine.
Customizable length.
Inlet can be 3/8" with 5/16" outlet.
Part #
Description
18-8002EP-1
Primer bulb for 1/4" hose
Numerous OEM connectors available.
18-8004EP-1
Primer bulb for 5/16" hose
18-8005EP-1
Primer bulb for 3/8" hose
BRACKETS
Sierra brackets are precision machined powder coated aluminum or marine grade
stainless steel. They are available with 3/8" or 1/4" inlets.
Part #
Part #
Standard
Bulk
Boxed
Description
Pack
N-187776
18-7776
3/8" Thread Stainless Steel
14
N-187777
18-7777
1/4" Thread Stainless Steel
14
N-187775
18-7775
3/8" Thread Aluminum
48
SUB-187852-1
18-7853-1
1/4" Thread Aluminum
48
N-187774S
18-7774
1/4" Thread Aluminum (Compact)
60
N-184264
18-4264
3/8" Pipe Plugs
--
5153R
18-4256
1/4" Pipe Plugs
--
84
