SHIELDS MULTIFLEX
Shields Multiflex Hose has
a clear FDA formula PVC
with black vinyl helix. It is
abrasion resistant, flexible and
is resistant to mild chemicals
and saltwater. This hose is
primarily used for bilge pump
discharge, potable water tank
fill and drains (sinks, shower,
livewell and scupper). This hose
uses 147 right hand thread
cuffs. Do not attach to thru
hull fitting below the water
Bulk Pack
Dist. Pkg.
10' (3.1m)
Bend
Wt.
100' (30.5m)
50' (15.2m)
Length
line. Do not use ethylene
I.D.
mm
Radius
mm
"C"
Coil Code #
R/O Ctn. Code #
Code #
/8"
/2"
16-141-0580B
16-141-0586B
15.9
12.7
8
5
1
glycol based antifreeze in
/4"
/4"
16-141-0340B
16-141-0346B
19.1
19.1
10
3
3
hose.
/8"
16-141-1000B
16-141-1006B
1"
25.4
22.2
13
7
1 1/8"
16-141-1180B
16-141-1186B
28.6
1"
25.4
16
1 1/4"
1  1/2"
16-141-1140B
16-141-1146B
31.8
38.1
19
1 1/2"
16-141-1120B
16-141-1126B
38.1
2"
50.8
24
16-141-2000B
16-141-2003B
2"
50.8
5"
127.0
34
-
1 1/2"
16-141-1120W
16-141-1123W
38.1
2"
50.8
24
-
SHIELDS vAC EXTRA HEAvY DUTY/FDA
Shields Vac Extra Heavy Duty/FDA Hose has a smooth
white FDA grade PVC with vinyl helix. It is rated for full
vacuum and is resistant to mild chemicals, permeation, and
saltwater. This hose is primarily used for bilge pump
intake and discharge, drains (sinks, shower, and scupper),
livewell intake and drain, potable water tank fill, and
sanitation (toilet to holding tank, intake, self draining
lines vent and pump out). This hose is resistant to odor
permeation. Do not use ethylene glycol
based antifreeze in hose. Do not use in
pressurized water systems.
Bulk Pack
Dist. Pkg.
Bend
vac
Wt.
100' (30.5m)
50' (15.2m)
25' (7.6m)
I.D.
mm
Radius
mm
Rating
"C"
Coil Code #
R/O Ctn. Code #
R/O Ctn. Code #
/8"
16-148-0580W
16-148-0586W
15.9
3
76.2
28
15
--
5
/4"
16-148-0340W
16-148-0346W
19.1
3
76.2
28
20
--
3
16-148-1000W
16-148-1006W 
1"
25.4
3
76.2
28
27
--
1 1/8"
16-148-1180W
16-148-1186W
28.6
4
101.6
28
29
--
1 1/4"
16-148-1140W
16-148-1146W
31.8
4
101.6
28
31
--
1 1/2"
16-148-1120W
16-148-1126W 
16-148-1125W
38.1
5
127.0
28
40
 WARNING: Lines containing raw sewage should be plumbed to be self-draining.
