UNSHROUDED
4 Pole Flat Connectors
Trailer Side
Shrouded connectors provide better protection against weather
dirt and moisture. Unshrouded connectors are found on most
OEM trailers. The plugs are interchangeable and can connect together.
Tow Vehicle Side
SHROUDED
White
Ground
Brown
Tail, License, Marker Lamps
Trailer Side
Yellow
Left Turn Signal/Stop Lamp
Green
Right Turn Signal/Stop Lamp
Tow Vehicle Side
Set of Both
Tow Vehicle Side
Trailer Side
Description
Halves Part #
Part Number
Wire Length
Part Number
Wire Length
TC43654
NSS
TC44054
4 pole Flat - Unshrouded
4-12"
4-12"
TC43674
TC44094
TC44054
4 pole Flat - Unshrouded
3-48", 1-18"
4-12"
TC43844
WH10180
TC44254
4 pole Flat - Shrouded
4-12"
4-12"
TC43724
4 pole Flat - Shrouded w/ splicers
TC44224
TC44254
4 pole Flat - Shrouded
3-48", 1-18"
4-12"
TC43754
TC44224
NSS
4 pole Flat - Shrouded rewire kit
3-48", 1-18"
4-20'
TC43744
TC44224
NSS
4 pole Flat - Shrouded rewire kit w/ Splicers
3-48", 1-18"
4-20'
WH10350
4 pole Flat - Shrouded 5' extension Harness
WH10003
4 pole Flat - Shrouded 25' rewire kit
4-25'
TC52000
TC52100
TC42884
TESTER
TESTER
TESTER
TC42984
DUST CAPS
Allows for quick and easy diagnosis of trailer/tow vehicle lighting problems; simply plug into vehicle
4 Pole Flat Dust Caps
trailer connector. LED lighting allows for each circuit to be quickly tested and evaluated.
5 Pole Flat Connectors
White
Ground
Brown
Tail, License, Marker Lamps
Yellow
Left Turn Signal/Stop Lamp
Green
Right Turn Signal/Stop Lamp
Blue
Trailer Brake Solenoid
Set of Both
Tow Vehicle Side
Trailer Side
Description
Halves Part #
Part Number
Wire Length
Part Number
Wire Length
TC51000
5 pole Flat - Unshrouded 18" extension Harness
TC51100
TC51200
5 pole Flat - Unshrouded
5-48"
5-70"
6 Pole Square Connectors
Similar to above except with 6 color coded wires to provide for 5 circuits PLUS ground.
Color codes are as follows:
White
Ground
Green
Right Turn Signal
Red
Stop Lamps
Brown
Tail & License Lamps
Blue
Auxiliary
Yellow
Left Turn Lamp
Trailer Side
Tow Vehicle Side
Tow Vehicle Side
Wire
Trailer Side
Wire
Part #
Description
Replacement
Length
Replacement
Length
53
TC43924  Shrouded set of both halves.
Not sold separately
48"
Not sold separately
12"
