Sierra Marine Parts Catalog
Fuse Block for Glass Tube Fuses - Standard Fuse Blocks
Part Number
# of Gangs
*FS40502-1
2
4
*FS40512-1
4
6
� Use with SFE, AGC, or MDL fuses up to 20 Amp
*FS40522-1
6
� Heavy duty black molded base
8
� 8-32 terminal screws
*FS40532-1
8
� Tin plated brass fuse clips
Hot Feed/Common Ground Fuse Blocks
Part Number
# of Gangs
4
*FS40632-1
4
� Use with SFE, AGC, or MDL fuses up to 20 Amp
� Common bus bar connects hot side of fuses for power feed
6
� Separate bus bar for ground or unfused common hot feed
*FS40642-1
6
� Heavy duty black molded base
� 8-32 stud terminals for power/ground connection
*FS40652-1
8
� 1/4" Q.D. terminals for circuit hookup
� Tin plated brass fuse clips
Part Number
# of Gangs
**FS40540
2
*FS40542-1
2
4
*FS40552-1
4
� Use with SFE, AGC, or MDL fuses up to 20 Amp
6
� Common bus bar connects hot side of fuses for power feed
� Separate bus bar for ground or unfused common hot feed
*FS40562-1
6
� Heavy duty black molded base
8
� 8-32 terminal screws and stud terminals for power/ground connection
*FS40572-1
8
� Tin plated brass fuse clips
Hot Feed Fuse Blocks
Part Number
# of Gangs
4
*FS40592-1
4
6
� Use with SFE, AGC, or MDL fuses up to 20 Amp
*FS40602-1
6
� Common bus bar connects hot side of fuses for power feed
� Heavy duty black molded base
8
� 8-32 terminal screws and stud terminal for power connection
*FS40612-1
8
� Tin plated brass fuse clips
48
*BULK - 100 pcs. per carton
**CLAMSHELL
