Tilt & Trim Motors (p. 28)

Table of Contents | < Previous Page|Next Page >

28
Images Referenced On Pages 43 - 56
OE No. Part No. Application
3857265
Low pressure / high flow
3857489
For: SX - Late Model with Coarse Thread
3858071
For: SX - Early Version / Fine thread & 2.5" bolt centers
3860879
For: SX - Late Model with Coarse Thread
3861575
For: SX Drives - Later Version / 2.3" Bolt Centers w/ Coarse Thread
YAmAHA
®
60V-43880-00-00
Fits: F200, F225 (2004-06), F250 (2005-06), LF200, LF225, LF250, LZ200, LZ225, LZ250 (2004-06)
61A-43880-01-00
For: 225-250HP
61A-43880-02-00
For: 225-250HP
62X-43880-00-00
Fits: 1995-99 40-50HP 4-Strokes
62X-43880-00-00
Fits: 1995-03 Yamaha 40-100HP
62X-43880-01-00
Fits: 1995-99 40-50HP 4-Strokes
62X-43880-01-00
Fits: 1995-03 Yamaha 40-100HP
62X-43880-09-00
Fits: 1995-03 Yamaha 40-100HP
62X-43880-09-00
Fits: Yamaha 40-100hp (1995-03)
64E-43880-00-00
2-wire ring terminal connection 4-bolt mount For: 115-225HP (1997-2002)
64E-43880-01-00
2-wire ring terminal connection 4-bolt mount For: 115-225HP (1997-2002)
67F-43880-00-00
Fits: Yamaha 4-Strokes F75 (2003-04), F80 (1999-03), F90 (2003-04), F100 (1999-02)
688-43880-11-00
Fits: Yamaha 50-200HP 1985-86
69J-43880-00-00
Fits: F200, F225 (2004-06), F250 (2005-06), LF200, LF225, LF250, LZ200, LZ225, LZ250 (2004-06)
6C5-43880-00-00
Fits: 2005-06 F50 and F60
6E5-43880-01-00
Fits: Yamaha 50-200HP 1985-86
6E5-43880-02-00
Fits: Yamaha 50-200HP 1985-86
6G5-43880-02-00
For: 115-200HP (1987-96)
6H1-43880-00-00
Fits:70/90HP (1987-91), C85/P60HP (1991)
6H1-43880-02-00
2-wire connection, 3 bolt mount For: 40HP (1994) 50HP (1992-95) 60HP (1997-up) 70HP (1996-up) 90HP (1992-
up)
6H5-43880-02-00
Fits: Yamaha 40-50hp (1985-92)
Universal
Fits: Engines with 3-Ram Trim Assembly, 115-225HP Johnson/Evinrude Engines
In many cases, replacements for older 3-wire til/trim motors are no longer manufactured or
available. In order to keep these applications operating, Sierra now offers replacement two wire
tilt/trim motors with all necessary wiring harness adapters and required relays to make these
conversions easy and painless.
