DRIVE SYSTEMS
WELCH PLUG
PLUG
19-32652
19-47579
7/8 Inch O.D.
For trim tab screw hole
Priced individually, sold @ multiples of 5
WELCH PLUG
19-42682
113/64 Inch O.D.
SHIM CHART - STERNDRIVE
Stern Drive Shim Chart
Model
Year Range
Serial # Range
Shim Kit - Upper
Shim Kit - Upper
Spacer Shim - Shim Kit - Upper
Shim Kit - Lower  Shim Kit -
Shim -
Cover Bearing
Drive Gear
Upper Drive
Driven Gear
Drive Shaft Upper Forward Gear
Reverse Gear
Gear
Bearing
Bearing
I
1963
1534570 - 1536617
15-32563A 1
N.L.A.
N/A
N.L.A.
N.L.A.
N.L.A.
15-29955A 1
I
1963
1536618 - 1684187
15-32563A 1
N.L.A.
N/A
N.L.A.
15-57007A 1
N.L.A.
15-29955A 1
IA/IB/IC & EZ Shift
1964 - 1966
1684188 - 2065186
15-32563A 1
15-35980A 1
N/A
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
120/140
1967
2062141 - 2187468
15-36178A02
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
120/140
1967 - 1969
2187469 - 2791956
15-32563A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
120/140
1970 - 1971
2791957 - 3134193
N/A
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
120/140
1971 - 1977
3213658 - 4893634
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
120/140
1978 - 1982
4893635 - 6225576
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-97166
470
1976 - 1977
4208730 - 4893934
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
470/485
1978 - 1982
4893835 - 6225575
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-97166
160
1967
2065190 - 2182197
15-36178A02
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
160
1967 - 1969
2182198 - 2763441
15-32563A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
165
1970 - 1971
2763442 - 3134193
N/A
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
165
1971 - 1977
3213658 - 4890459
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
165
1978 - 1981
4890460 and up
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-97166
888
1971 - 1972
3106717 - 3472477
N/A
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
888
1973 - 1977
3472478 and up
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
225-S
1974
3856268 - 4200499
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
233
1975 - 1977
4200500 and up
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
898/228
1977
4782330 - 4898729
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
898/228
1978 - 1982
4898730 - 6225576
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-97166
250
1977
4791300 - 4898729
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-31535A 1
260
1978 - 1982
4898730 - 6225576
15-45691A 1
15-35980A 1
15-71013
15-36178A02
15-57007A 1
15-47397A 1
15-97166
