ELECTRICAL SYSTEM
Model
Model Note
Serial # Range
Standard Stator
OPTIONAL Stator CONVERTS 9
AMP TO 16 AMP
V-175 Carbed
Black 16 amp stator w/ non-louvred cover &
USA
0C239553 - 0D081999
398-5454A35
N/A
coated stator wires
V-175 Carbed
Black 16 amp stator w/ louvred cover &
USA
0C239553 - 0D081999
398-9873A 4
N/A
coated stator wires
V-175 Carbed
Clear 40 amp stator w/ louvred cover &
USA
0C239553 - 0D081999
398-9610A 5
N/A
visible stator wires
V-175 Carbed
USA
0D082000 - 0G960499
398-9610A19
N/A
V-175 EFI
USA
0D000749 - 0D081999
398-9610A 5
N/A
V-175 EFI
USA
0D082000 - 0G960499
398-9610A19
N/A
V-175 EFI
USA
0G960500 - 0T408999
-
N/A
V-200 (200, 2000) Carbed
USA
4839034 - 6625220
398-5454A 7
N/A
V-200 (200, 2000) Carbed
AUS
8061595 - 8065672
398-5454A 7
N/A
V-200 Carbed
Without voltage regulator.
USA
6618751 - 0C100860
398-5454A 7
N/A
V-200 Carbed
With voltage regulator and 1/2 inch stator
USA
6618751 - 0C100860
398-5454A32
N/A
laminations
V-200 Carbed
With voltage regulator and 5/8 inch stator
USA
6618751 - 0C100860
398-5454A35
N/A
laminations
V-200 Carbed
Black 16 amp stator w/ non-louvred cover &
USA
0C100861 - 0C291519
398-5454A35
N/A
coated stator wires
V-200 Carbed
Clear 40 amp stator w/ louvred cover &
USA
0C100861 - 0C291519
398-9610A 5
N/A
visible stator wires
V-200 Carbed
Black 16 amp stator w/ non-louvred cover &
USA
0C291520 - 0D081999
398-5454A35
N/A
coated stator wires
V-200 Carbed
Black 16 amp stator w/ louvred cover &
USA
0C291520 - 0D081999
398-9873A 4
N/A
coated stator wires
V-200 Carbed
Clear 40 amp stator w/ louvred cover &
USA
0C291520 - 0D081999
398-9610A 5
N/A
visible stator wires
V-200 Carbed
USA
0D082000 - 0G960499
398-9610A19
N/A
V-200 EFI
USA
0C100861 - 0D081999
398-9610A 5
N/A
V-200 EFI
USA
0D082000 - 0G960499
398-9610A19
N/A
V-200 EFI (2.5L)
USA
0G960500 - 0T408999
-
N/A
V-220 Laser
USA
0B117316 and up
398-5454A35
N/A
V-225 Carbed (2.4L)
USA
5628028 and up
398-5454A 7
N/A
V-225 Carbed (3.0L)
USA
0D280813 - 0G129221
398-821935A 3
N/A
V-225 Carbed (3.0L)
USA
0G129222 - 0T408999
398-821935A 5
N/A
V-225 EFI
USA
0G129222 - 0T408999
398-821935A 5
N/A
V-250 EFI
USA
0G129222 - 0T408999
398-821935A 5
N/A
V-250 Carbed (3.4L)
Mounted with 4 standard screws and used
USA
0C101891 and up
N.L.A.
N/A
with water cooled voltage regulator
V-250 Carbed (3.4L)
Mounted with 5 metric screws and used with
USA
0C101891 and up
N.L.A.
N/A
water cooled voltage regulator
V-250 Carbed (3.4L)
Mounted with 5 metric screws and used with
USA
0C101891 and up
N.L.A.
N/A
815279T voltage regulator
V-300 Carbed (3.4L)
USA
5611648 and up
398-5454A55
N/A
(1) Outboards using 16 amp kit will require the installation of a new style attenuator plate part no. 42970A 2, to provide a mounting location for the voltage regulator.
