ACCESSORY KITS FOR PLUS-SERIES ENGINES
SEAWATER PUMP KIT
46-862914A06
Fits 2001 and newer MCM V6 & V8 (305 & 350 cid) Alpha engines (s/n
0M300000 and up). Use only in conjunction with closed cooling kit. See closed
cooling application chart.
CLOSED COOLING CHART
Closed Cooling Kits PlusSeries Engines
Engine Model
Plus-
Closed
Belt Kit
Seawater Pump ECM
Series P/N Cooling
Kit
Kit
MCM 3.0L TKS
8M0064799 61086A11 N/A
N/A
N/A
MCM 4.3L Alpha 4V
865108R89 860427A 6
N/A
N/A
MCM 357 Alpha
865108R88 860427A 5 807901A 5
46-807151A 5(2) N/A
MCM 357 Mag Bravo
865108R85 860427A 5 807901A 5
N/A
N/A
MCM 350 Mag MPI Alpha
863611R11 864920A02 N/A
46-862914A06(2) 865839T02(1)
MCM 383 Mag Bravo
865108R90 860427A 7 N/A
N/A
N/A
MCM 383 Mag Stroker
865108R80 864920A02 N/A
N/A
865008T04(1)
MIE 383 Mag (LH) Std. Rotation
8M0061212 860427A 5 N/A
N/A
N/A
MIE 383 Mag (RH) Opp. Rotation 8M0061213 860427A 5 N/A
N/A
N/A
(1) The ECM must be replaced when installing a closed cooling kit. For MCM 350 MPI Alpha - Order ECM p/n
865839T02. For MCM 383 Mag Stroker - Order ECM p/n 865008T04.
(2) Thru hull water pickup is not included with seawater pump kits. Obtain locally.
14-10 PIN HARNESS ADAPTOR
ADAPTER - NON DTS 14 PIN TO 10 PIN
84-866337T01
Adapter that allows you to connect engines that have the newer 14 pin engine
harness to the older 10 pin helm harness
MCM/MIE engines that have the 14 pin engine harness. Also used on Race
product (outboards only) that have a 14 pin engine harness being connected to a
10 pin helm harness.
