ACCESSORY KITS FOR PLUS-SERIES ENGINES
EXHAUST "Y" PIPE KIT
INTERMEDIATE ELBOW KIT
Only required on sterndrive engines that have the exhaust going through the prop.
For use with Silent Choice type exhaust systems. Also used to convert engines
with thru transom exhaust to thru prop exhaust. Standard pipe on all thru prop
Fits MCM V‑8 (305, 350 & 377 cid) engines with 3 in. (76 mm) risers (s/n
exhaust gasoline sterndrive models.
0W310000 and up)
Fits all V‑8 engines with 4 in.(102 mm) exhaust systems; except MCM 8.1L & 8.2L
engines
INTERMEDIATE ELBOW KIT
EXHAUST RISER CHART
Exhaust Riser Kits ‑ Plus‑Series Engines
Engine Model
Plus-Series Riser Height
Riser Kit
Intermediate
P/N
Elbow Kit
MCM 4.3L Alpha 4V
865108R89 3 in. (76 mm)
14865A02(1)
6 in. (152 mm)
14865A 1(1)
MCM 357 Alpha
865108R88 3 in. (76 mm)
14865A02(1)
Only required on sterndrive engines that have the exhaust going through the prop.
6 in. (152 mm)
14865A 1(1)
Fits MCM V‑8 (305, 350 & 377 cid) engines with 4.7 in. (119 mm) risers (s/n
MCM 357 Mag Bravo
865108R85 3 in. (76 mm)
14865A02(1)
0W310000 and up)
6 in. (152 mm)
14865A 1(1)
INTERMEDIATE ELBOW KIT
MCM 350 Mag MPI Alpha
863611R11 3 in. (76 mm)
14801A 1(1)
6 in. (152 mm)
14801A 1(1)
MCM 383 Mag Bravo
865108R90 1.7 in.(43 mm)
866003A01(1)
3 in. (76 mm)
866004A01(1)
4.7 in.(119 mm) 866208A02
866209A01(1)
6 in. (152 mm)
866005A01(1)
MCM 383 Mag Stroker
865108R80 1.7 in.(43 mm)
866003A01(1)
3 in. (76 mm)
866004A01(1)
4.7 in.(119 mm) 866208A02
866209A01(1)
6 in. (152 mm)
866005A01(1)
MIE 383 Mag (LH) Std. Rotation
8M0061212 1.7 in.(43 mm)
865995A01(2)
N/A
Only required on sterndrive engines that have the exhaust going through the prop.
3 in. (76 mm)
864929A 3(2)
N/A
Fits MCM V‑8 (305, 350 & 377 cid) engines with 6 in. (152 mm) risers (s/n
4.7 in.(119 mm) 866208A02(2)
N/A
0W310000 and up)
6 in. (152 mm)
864908A 1(2)
N/A
MIE 383 Mag (RH) Opp. Rotation 8M0061213 1.7 in.(43 mm)
865995A01(2)
N/A
3 in. (76 mm)
864929A 3(2)
N/A
4.7 in.(119 mm) 866208A02(2)
N/A
6 in. (152 mm)
864908A 1(2)
N/A
MIE 8.1L Horizon (V-drive)
8M0052317 4 in. (102 mm)
N/A
6 in. (152 mm)
N/A
MIE 8.1L Horizon (Down-angle)
8M0052318 4 in. (102 mm)
N/A
6 in. (152 mm)
N/A
(1) Intermediate Elbow Kit listed is only required on sterndrive engines that have the exhaust going
thru the prop
(2) The Remote Oil Filter Bracket may need to be relocated when installing an Exhaust Riser Kit.
394
