INSTALLATION SPECIFICATIONS AND TOOLS
INSTALLATION SPECIFICATIONS AND TOOLS
DRILL FIXTURE KIT
INSTALLATION AIDS
TRANSOM DRILLING FIXTURE
Used to assist drilling of the holes for the MerCruiser transom plate mounting bolts.
For MCM 3.0L to 350 Magnum (Alpha One), Bravo One, Two, Three and
Blackhawk models.
Used to assist drilling of the holes for the outboard engine transom bracket
mounting bolts.
ENGINE MOUNTING FIXTURE
Mercury/Mariner 30/40 hp. & above (2 cycle), 25 hp. Bigfoot & above (4‑Stroke),
and Force 40 hp. & above (1993 and newer).
CONTROL DRILLING FIXTURE
Gasoline engine mount installation tool fixture.
For MerCruiser 1.6L Vazer engines.
ENGINE MOUNTING FIXTURE
Used to assist drilling of the holes for side mount control and panel mount control
mounting bolts.
For use with the Commander 2000 side mount and the Commander 3000 panel
mount controls.
DRILL FIXTURE KIT
Gasoline engine mount installation tool fixture.
MerCruiser gasoline engines, except Vazer engines.
Diesel engine mount installation tool fixture.
MerCruiser 2.8 ES (s/n 88010499 and below), D3.0 L, D3.6 L; D4.2 MS / ES (s/n
88020199 and below)
ENGINE MOUNTING FIXTURE
Used to assist drilling of the holes for the MerCruiser transom plate mounting bolts.
For MCM 1.6L Vazer models.
Diesel engine mount installation tool fixture.
Fits all QSD 2.0L, 2.8L & 4.2 engines
Also fits 1.7L, 2.8L & 4.2L (Tier 1) engines
US Quicksilver Product Guide
309
