REMOTE CONTROLS
SIDE MOUNT REMOTE CONTROL- 8 PIN TRADITIONAL
SIDE MOUNT REMOTE CONTROL- 8 PIN TRADITIONAL
881170A15
881170A20
For power trim models, 15 ft.(4.58 m) harness and builtin warning horn. New
For power trim models, 20 ft.(4.58 m) harness and builtin warning horn. New
design which includes soft grip and power trim leads for front mount switch. Ref.
design which includes soft grip and power trim leads for front mount switch. Ref.
Throttle/shift cable Gen I 897977A__. Throttle/Shift cables (896143A) for
Throttle/shift cable Gen I 897977A__. Throttle/Shift cables (896143A) for
MY2005 and newer 8/9.9 FourStroke outboards. 89.9 4 Stroke engines
MY2005 and newer 8/9.9 FourStroke outboards. 89.9 4 Stroke engines
generation change above S/N OR192772 and new 15/20 4 Stroke engines will use
generation change above S/N OR192772 and new 15/20 4 Stroke engines will use
Gen I series T/S Cables
Gen I series T/S Cables
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and
Fits all current Mercury/Mariner outboards (with integral power trim) and 1993 and
newer Force outboards 40 hp and higher utilizing Mercury style cables (with power
newer Force outboards 40 hp and higher utilizing Mercury style cables (with power
trim). When used with MY2005 and newer 8/9.9/15/20 FourStroke outboards an
trim). When used with MY2005 and newer 8/9.9/15/20 FourStroke outboards an
adapter harness 84-892473A01 is required. Remote Control cables need Gen I
adapter harness 84-892473A01 is required. Remote Control cables need Gen I
style to connect to control box.
style to connect to control box.
SIDE MOUNT REMOTE CONTROL- 14 PIN
PANEL MOUNT CONTROLS
Use on Mercury Outboards or Mercruiser
MPC PANEL-GEN II- FINGER RELEASE-O/B (CHROME)
881170A16
For nonpower trim models, 15 ft.(4.58 m) harness and builtin warning horn. New
design with soft grip. Ref. Throttle/shift cable Gen I 897977A__. Throttle/Shift
cables (896143A) for MY2005 and newer 8/9.9 FourStroke outboards. 89.9 4
Stroke engines generation change above S/N OR192772 and new 15/20 4 Stroke
engines will use Gen I series T/S Cables
Fits all current Mercury/Mariner outboards 6 hp. and above (without power trim),
8M0030550
and 1993 and newer Force outboards 40 hp and higher utilizing Mercury style
cables (with power trim). When used with a MY2005 and newer 8/9.9/15/20
Comes with 4 ft.(1.22 m) trim harness with the 3 pin Molex connector. All
FourStroke outboard an adapter harness 892473A01 is required. Gen I cable must
installations require a separate Ignition/Choke assembly and Throttle/Shift Cables
be used with this control
to complete the installation. Power trim adapter harness included to convert 3 pin
Molex connector to the traditional 3 blade Mercury connector. Neutral safety switch
leads are 6.5 ft.(1.98 m) long and have bullet connectors on the ends. Lanyard
switch leads also have bullet connectors on ends. Must use Gen II Throttle/Shift
Cables design. ( 897978A__) 89.9 4 Stroke engines 2005 and newer will use
896145A series and 8/9.9/generation change above S/N OR192772 and 15/20 4
Stroke will use Gen II series T/S Cable
Fits all current Mercury/Mariner outboards (with integral trim) and 1993 and newer
Force outboards 40 hp and higher utilizing Mercury style cables (with power trim).
(See note above for correct T/S cables for 89.9 4 stroke engines)
Mercury Branded
US Quicksilver Product Guide
271
