PROPELLER HARDWARE AND ACCESSORIES
FLO-TORQ II HUB KIT SUZUKI
FLO-TORQ II HUB KIT
835281Q 1
835270Q 1
12-853359
12-835467 7 Forward thrust washer
Fwd thrust washer
835290A1
Plastic drive sleeve
835290A1
Plastic drive sleeve
826074Q 1
Aft adaptor
850330Q
Aft adaptor
12-31211A 3
Washer
879143
Spacer
859939
Nut
802126Q 1
Nut
18-47959
Cotter Pin
Cotter pin included with Nut
Suzuki 150225 HP 2Stroke Outboards and 150250 HP 4Stroke Outboards. Can
OMC Cobra/Volvo SX sterndrives (19 tooth spline, 1996present)
be used with Mercury Racing propellers.
Caution! When installing stainless steel propellers, remove the anode to bearing
carrier and check clearance before operation.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT SUZUKI
FLO-TORQ II HUB KIT YAMAHA
835283Q03
835272Q 1
128M80042329
Fwd thrust washer
12-853555Q Forward thrust washer
835290Q 1
Plastic drive sleeve
835290A1  Plastic drive sleeve
826074Q 1
Aft adaptor
826074Q 1 Aft adaptor
12-887972
Washer
12-850076 Spacer
859939
Nut
859939 Nut
18-47959
Cotter Pin
18-47959 Cotter Pin
Suzuki 7090 HP 2009 and Newer
Yamaha outboards (50100 HP, splined forward thrust washer)
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
FLO-TORQ II HUB KIT TOHATSU
FLO-TORQ III HUB KIT YAMAHA
835284Q 1
835272Q09
12-853948T  Fwd thrust washer
12-853555Q Forward thrust washer
835290A1
Plastic drive sleeve
881940A 1 Drive Sleeve Assembly
826074Q1
Aft adaptor
878584 Aft adaptor
12-16140
Washer
12-850076 Spacer
11-16147
Nut
859939 Nut
18-815026
Cotter Pin
18-47959 Cotter Pin
Tohatsu/Nissan (70C, 90140 HP)
Yamaha outboards (50100 HP, splined forward thrust washer)
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Quicksilver Branded, Hanging Box Point of Sale Packaged.
US Quicksilver Product Guide
123
