PROPELLER HARDWARE AND ACCESSORIES
Evinrude/Johnson/OMC & Volvo SX Flo‑Torq
Application
Flo-Torq II Hub Kit Forward Trust Washer Drive Sleeve
Bushing Aft Adaptor Aft Spacer/ Washer Nut
Cotter Pin
Evinrude/Johnson V-4
835266Q 1(1)
835290Q1(Delrin) N/A
N/A
Johnson 90-115 HP 4-Stroke
835290Q1(Delrin) N/A
Johnson 140 HP 4-Stroke Outboard
835290Q1(Delrin) N/A
Evinrude/Johnson/OMC Stern Drives V-6, V-8 1991 & Newer
835290Q1(Delrin) N/A
Included with Nut
802009Q 1 Included with Nut
Evinrude/Johnson 250 V-6 2002 & Newer
835290Q1(Delrin) N/A
Included with Nut
802009Q 1 Included with Nut
Evinrude/Johnson/OMC Stern Drives V-6, V-8/ 1990 & Older
835290Q1(Delrin) N/A
Included with Nut
802009Q 1 Included with Nut
OMC Cobra SX/Volvo SX 1994 & Newer (19 tooth spline)
835290Q1(Delrin) N/A
802126Q 1 Included with Nut
(1) Use hub kit only with Quicksilver small lybrinth seal propellers: QA2202X thru QA2208X, QA 3828X thru QA3832X and QS5136X thru QS5144X.
Honda Flo‑Torq
Application
Flo-Torq II Hub Kit
Forward Trust Washer
Drive Sleeve
Bushing
Aft Adaptor
Aft Spacer/ Washer
Nut
Cotter Pin
Honda 75-90 HP 1999 & Newer, 115-130 HP All YRS.
835290Q1(Delrin)
N/A
N/A
Honda 75-90 HP thru 1998
835290Q1(Delrin)
N/A
N/A
Honda 135-225 HP 4-Stroke
835290Q1(Delrin)
N/A
Suzuki & Tohatsu/Nissan Flo‑Torq
Application
Flo-Torq II Hub Kit Forward Trust Washer Drive Sleeve Bushing Aft Adaptor Aft Spacer/ Washer Nut
Cotter Pin
Suzuki 60 HP 4-Stroke (1998 and newer), 70 HP 4-Stroke (1998-2008), 75-140
835282Q 1(1)
N/A
HP 2-Stroke
Suzuki 70-90 HP (2009 and newer)
N/A
Suzuki 90-115 HP 4-Stroke (2001-2008)
N/A
Suzuki 140 HP 4-Stroke, 100-115 HP 4-Stroke (2009 and newer)
N/A
Suzuki 150-300 HP
N/A
Tohatsu/Nissan 60-140 HP
N/A
(1) Use hub kit only with Quicksilver small lybrinth seal propellers: QA2202X thru QA2208X, QA 3828X thru QA3832X and QS5136X thru QS5144X.
FLO-TORQ REFLEX HUB KIT MERCURY
FLO-TORQ REFLEX HUB KITS
Kit includes: Forward thrust washer, Reflex drive sleeve (8M0047148), Aft Washer
FLO-TORQ REFLEX HUB KIT QUICKSILVER
and Prop Nut.
Mercury/Mariner 40‑60 HP FourStroke (not BigFoot), 30 HP FourStroke
1994‑2005, 30‑60 HP 2‑Stroke 1977 and newer, 25 HP BigFoot, 55 HP SeaPro/
Marathon, Yamaha 40‑60 HP (Excluding 50T and 60T), Honda 40‑50 HP with
separately purchased 8M0046466 Thrust Washer
Mercury Branded, Hanging Box Point of Sale Packaged.
DRIVE SLEEVE
Kit includes: Forward thrust washer, Reflex drive sleeve (8M0047148), Aft Washer
and Prop Nut.
Mercury/Mariner 40‑60 HP FourStroke (not BigFoot), 30 HP FourStroke
1994‑2005, 30‑60 HP 2‑Stroke 1977 and newer, 25 HP BigFoot, 55 HP SeaPro/
Marathon, Yamaha 40‑60 HP (Excluding 50T and 60T), Honda 40‑50 HP with
separately purchased 8M0046466 Thrust Washer
Quicksilver Branded, Hanging Box Point of Sale Packaged.
Plastic drive sleeve Flo‑Torq Reflex Composite Drive Sleeve
US Quicksilver Product Guide
119
