MERCURY/MARINER OUTBOARD APPLICATION CHARTS
MERCURY/MARINER OUTBOARD APPLICATION CHARTS
2.5 3.5 Horsepower Mercury/Mariner
2.5 3.5 Horsepower
2.5 HP 1990 & Newer
3 HP 1990 1992
3.3 HP 1993 & Newer
Pin Drive
Length (ft/m)
Propeller Size
Matl
Blades
Style
Quicksilver P/N
OEM P/N
Hub System
All Purpose
7 3/8 X 6 RH
AL
3
Black Diamond
QA3180
48-815084A01
Rubber Hub
46 Horsepower Mercury/Mariner
4 6 Horspower
4 5 HP 2Stroke 1987 & Newer
4, 5, 6 HP Stroke 1999 & Newer
12 Tooth Spline
Length (ft/m)
Propeller Size
Matl
Blades
Style
Quicksilver P/N
OEM P/N
Hub System
All Purpose
7.8 X 7 RH
AL
3
Black Diamond
QA3182R
48-812949A02(1)
Rubber Bushing
All Purpose
7.8 X 8 RH
AL
3
Black Diamond
QA3184R
48-812950A02(2)
Rubber Bushing
(1) Standard with 4 Hp, 2-Stroke and FourStroke
(2) Standard with 5 and 6 Hp FourStroke
Mercury 75 (7.5HP) and 110 (9.8HP)
Mercury 75 (7.5HP) and 110(9.8) 19681984
8 Spline
1968 thru 1978 Thrust Hub 86665A1 Spacer 11-64075A 1 Nut 11-46335 Washer
12-27025
1972 thru 1978 Nut 11-64075A 1
Length
Current MPH
Propeller Size
Material
Blades
Style
Quicksilver P/N
OEM P/N
To 15'
Up to 20
9 X 9 RH
AL
2
Black Diamond
48-47922A 10
48-47922A 10
15-17
12-18
8-3/8 X 8 RH
AL
3
Black Diamond
48-87572A 10
48-87572A 10
17 and up
10-16
8 3/4 X 7RH
AL
3
Black Diamond
48-47670A 10
48-47670A 10
8 Horsepower Mercury/Mariner
8 HP 197684 Mariner
Pin Drive
Length (ft/m)
Current MPH/KPH
Propeller Size
Matl
Blades
Style
Quicksilver P/N
OEM P/N
Hub System
14-18 / 4.2-5.5
to 15 / to 24
8 X 7 RH
AL
3
Black Diamond
QA3178R
82764
Rubber Bushing
8/9.9 Horsepower (4Stroke) Mercury/Mariner
8/9.9 (4Stroke) 2005 and newer
Std. gearcase only (Not Bigfoot)
12 Tooth Spline
Length (ft/m)
Current MPH/KPH
Propeller Size
Material
Blades
Style
Quicksilver P/N
OEM P/N
Hub System
Kicker
8.7 x 5 RH
Alum
4
Black Diamond
QA2148R
48-812954A10
Rubber Bushing
16 + / 4.8 +
to 12 / to 19
8.9 x 6.5 RH
Alum
3
Black Diamond
QA2150R
48-897610A10
Rubber Bushing
14-17 / 4.2-5.2
8-17 / 14-27
8.9 x 7.5 RH
Alum
3
Black Diamond
QA2154R
48-897614A10(1)
Rubber Bushing
13-16 / 3.9-4.8
12-21 / 19-34
8.9 x 8.5 RH
Alum
3
Black Diamond
QA2158R
48-897618A10(2)
Rubber Bushing
12-16 / 3.6-4.8
16-24 / 26-39
8.9 x 9.5 RH
Alum
3
Black Diamond
QA2160R
48-897620A10
Rubber Bushing
(1) Standard with 8 Hp FourStroke
(2) Standard with 9.9 Hp FourStroke
615 Horsepower Mercury/Mariner
6, 8, 9.9 and 15 HP 2Strokes 1986 & Newer
10, 15 HP Seapro/Marathon 1995 & Newer
8/9.9 HP (Not Bigfoot) 4Strokes 19952004
15 HP 4 Stroke 19892006
8 Tooth Spline
