Parts for Mercury Marine 350 Carburetor Assembly

Revise Search: All Models > 350 > 1571114 - 1812753 > Carburetor Assembly

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#	1399-2238	REAPIR PARTS KIT (1,1 required per assembly)
		1399-2238 - Repair Parts Kit [ More info ] Unavailable
		1395-9257 - Carburetor Repair Kit [ More info ] Unavailable
		1395-9262 1 - Carburetor Repair Kit - See Notes On Detail Page [ More info ] $101.54 10+ In Stock.
#	1399-2015	GASKET AND PACKING SET (1,1 required per assembly)
		1399-2015 - Carburetor Gasket Set [ More info ] $12.90 5 In Stock.
		18-7006-1 - Carburetor Gasket Set, 1399-1717 and 1399-2015 [ More info ] $8.99 $8.14 10+ In Stock.
#1	1335-2210	CARBURETOR ASSEMBLY, COMPLETE (KC-4A) (1,1 required per assembly)
		1335-2210 - Carburetor, NLA [ More info ] Unavailable
#2	1399-110A 1	FLOAT ASSEMBLY (1,1 required per assembly)
		1399-110A 1 - FLOAT ASSY Note: Priced Individually [ More info ] Unavailable
		1395-8983 - Float Assembly [ More info ] Unavailable
		1395-8673 - Float [ More info ] $19.45 10+ In Stock.
		18-7208 - Float 1395-8983, 1359-8673 [ More info ] $14.95 10+ In Stock.
#3	17-20853	PIN, FLOAT LEVER PINION (2,2 required per assembly)
		17-20853 - Pin, Float Lever, NLA [ More info ] $2.20 10+ In Stock.
#4	1399-102	LEVER, FLOAT (LOWER) (1,1 required per assembly)
		1399-102 - Lever [ More info ] $2.78 10+ In Stock.
#5	1399-101	LEVER, FLOAT (UPPER) (1,1 required per assembly)
		1399-101 - Lever [ More info ] $6.67 10+ In Stock.
#6	1399-1473	INLET NEELDE, SEAT AND GASKET (1,1 required per assembly)
		1399-1473 - Inlet Needle - Priced Individually [ More info ] Unavailable
		1395-9258 - Inlet Needle & Seat [ More info ] Unavailable
		1395-9258 1 - Valve Seat Kit [ More info ] $17.30 10+ In Stock.
		18-7057 - Needle And Seat 1395-9258 [ More info ] $10.99 $10.20 10+ In Stock.
#7	27-25033	GASKET, INLET SEAT (1,1 required per assembly)
		27-25033 - Inlet Seal Gasket [ More info ] $2.77 10+ In Stock.
#8	1399-99	GASKET, FLOAT BOWL COVER (1,1 required per assembly)
		1399-99 - Float Bowl Cover Gasket [ More info ] $1.60 10+ In Stock.
#9	1399-1133	COVER, FLOAT BOWL (1,1 required per assembly)
		1399-1133 - Float Bowl Cover [ More info ] $183.50 $155.98 10+ In Stock.
#10	10-20854	SCREW, FLOAT BOWL COVER (SHORT) (1,1 required per assembly)
		10-20854 - SCREW Note: Priced Individually [ More info ] Unavailable
		10-22625 - Screw, NLA [ More info ] $3.33 10+ In Stock.
#11	10-25850	SCREW, FLOAT BOWL COVER (LONG) (1,1 required per assembly)
		10-25850 - Screw, NLA [ More info ] $1.66 8 In Stock.
#12	27-34614	GASKET, STRAINER COVER (LARGE) (1,1 required per assembly)
		27-34614 - Strainer Cover Gasket [ More info ] Unavailable
		27-25851 - Strainer Cover Gasket [ More info ] $1.00 10+ In Stock.
#13	1399-1754	SCREEN, FILTER (1,1 required per assembly)
		1399-1754 - FILTER Note: Priced Individually [ More info ] Unavailable
		1399-3938 - Screen, NLA [ More info ] $6.75 10+ In Stock.
		18-7832 - Filter, 1399-3938 [ More info ] $11.29 $10.99 5 In Stock.
#14	27-25849	GASKET, STRAINER COVER (SMALL) (1,1 required per assembly)
		27-25849 - Strainer Cover Gasket [ More info ] $1.20 10+ In Stock.
#15	1399-2371	COVER, STRAINER (1,1 required per assembly)
		1399-2371 - Cover, NLA [ More info ] Unavailable
#16	27-25848	GASKET, STRAINER COVER SCREW (1,1 required per assembly)
		27-25848 - Cover Screw Gasket [ More info ] $2.60 10+ In Stock.
#17	10-25822	SCREW, STRAINER COVER (1,1 required per assembly)
		10-25822 - Screw, NLA [ More info ] $2.21 10+ In Stock.
#18	10-20847	SCREW, THROTTLE STOP LEVER (1,1 required per assembly)
		10-20847 - 10-20847 - SCREW [ More info ] Unavailable Replaced by 1395-6027
		1395-6027 - Screw [ More info ] $2.90 10+ In Stock.
#19	1399-97	LEVER, THROTTLE STOP (1,1 required per assembly)
		1399-97 - Throttle Lever [ More info ] Unavailable
		814679 1 - Throttle Lever [ More info ] $8.89 10+ In Stock.
#20	1399-2012	SHAFT, THROTTLE (1,1 required per assembly)
		1399-2012 - Throttle Shaft [ More info ] $17.78 10+ In Stock.
#21	1399-2178	TUBE, IDLE (1,1 required per assembly)
		1399-2178 - Idle Tube, NLA [ More info ] Unavailable
#22	27-23180	GASKET, IDLE TUBE (1,1 required per assembly)
		27-23180 - Idle Jet Gasket [ More info ] $3.76 10+ In Stock.
#23	10-23035	SCREW AND LOCKWASHER, THROTTLE SHUTTER (2,2 required per assembly)
		10-23035 - Screw, NLA [ More info ] $1.96 10+ In Stock.
#24	1399-2237	SHUTTER, THROTTLE (1,1 required per assembly)
		1399-2237 - Throttle Shaft,NLA [ More info ] Unavailable
#25	19-32299	WELCH PLUG, BODY CHANNEL (1,1 required per assembly)
		19-32299 - Plug, NLA [ More info ] $2.50 10+ In Stock.
#26	24-26890	SPRING, THROTTLE SHAFT RETURN (1,1 required per assembly)
		24-26890 - Spring, Throttle Shaft Return,NLA [ More info ] $2.50 10+ In Stock.
#27	1399-2418	MAIN NOZZLE (1,1 required per assembly)
		1399-2418 - Main Nozzle,NLA [ More info ] Unavailable
#28	10-28846	SCREW, PLUG - MAIN NOZZLE (1,1 required per assembly)
		10-28846 - SCREW,NLA [ More info ] Unavailable
#29	1399-2011	JET, MAIN FUEL (.071) (OPT,OPT required per assembly)
		1399-2011 - Jet 071, NLA [ More info ] $7.50 10+ In Stock.
#29	1399-1962	JET, MAIN FUEL (.069) - STANDARD (1,1 required per assembly)
		1399-1962 - Jet 069, NLA [ More info ] $11.11 10+ In Stock.
#29	1399-1467	JET, MAIN FUEL (.067) (OPT,OPT required per assembly)
		1399-1467 - Jet -.067, NLA [ More info ] $9.99 10+ In Stock.
#29	1399-1465	JET, MAIN FUEL (.065) (OPT,OPT required per assembly)
		1399-1465 - Jet 065, NLA [ More info ] $9.99 10+ In Stock.
#30	27-28409	GASKET, MAIN FUEL JET (1,1 required per assembly)
		27-28409 - Main Fuel Jet Gasket [ More info ] $5.54 10+ In Stock.
#31	27-28406	GASKET, JET CHANNEL PLUG SCREW (1,1 required per assembly)
		27-28406 - Inlet Needle Gasket [ More info ] Unavailable
#32	10-28405	SCREW, PLUG - MAIN FUEL JET CHANNEL (1,1 required per assembly)
		10-28405 - Screw, NLA [ More info ] $4.59 10+ In Stock.
#33	1399-1713	SCREW, IDLE ADJUSTMENT (1,1 required per assembly)
		1399-1713 - Idle Adj Screw, NLA [ More info ] $22.00 10+ In Stock.
#34	24-27160	SPRING, IDLE ADJUSTMENT SCREW (1,1 required per assembly)
		24-27160 - Spring, Idle Adjusting Screw [ More info ] $3.90 10+ In Stock.
#35	27-31402	GASKET, CARBURETOR FLANGE (1,1 required per assembly)
		27-31402 - Carburetor Flange Gasket [ More info ] $2.50 10+ In Stock.
		18-2571-9 - Gasket 27-31402 2-Pack [ More info ] $5.24 Available to Order: Usually ships within 10 days.
#36	11-29250	NUT, CARBURETOR MOUNTING STUDS (2,2 required per assembly)
		11-29250 - Nut (5/16-24) [ More info ] $2.80 $1.57 10+ In Stock.
