Parts for Mercury Marine Remote Controls & Components Attaching Kit - Remote Control (16840A2)

Revise Search: All Models > Remote Controls & Components > 1986 - 1993 > Attaching Kit - Remote Control (16840A2)

NEED PARTS OR KITS?
View diagram and parts list below. Tap to zoom. Scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	16840A 2	REMOTE CONTROL ATTACHING KIT (1 required per assembly)
		16840A 2 - Remote Control Attaching Kit [ More info ] Unavailable
#2	16848	LEVER (1 required per assembly)
		16848 - Lever [ More info ] $17.17 Available to Order: Usually ships within 10 days.
#3	17034	THROTTLEWIRE (1 required per assembly)
		17034 - Wire - Throttle [ More info ] $4.20 Available to Order: Usually ships within 10 days.
#4	10-16223	BOLT (1 required per assembly)
		10-16223 - Bolt [ More info ] $4.00 $0.80 10+ In Stock.
#6	12-16237	WASHER (1 required per assembly)
		12-16237 - WASHER [ More info ] $0.88 1 In Stock.
		12-95392 1 - Washer [ More info ] $5.40 4 In Stock.
#7	23-16849	COLLAR (1 required per assembly)
		23-16849 - Collar [ More info ] $10.30 Available to Order: Usually ships within 10 days.
#8	84-17035	HARNESS (DUAL STOP SWITCH) (1 required per assembly)
		84-17035 - Harness Assembly [ More info ] $10.20 Available to Order: Usually ships within 10 days.
#9	17-17031	LOCK PIN (1 required per assembly)
		17-17031 - Lock Pin [ More info ] $26.63 1 In Stock.
#10	17-17033	PIN (1 required per assembly)
		17-17033 - Spring,Pin [ More info ] $3.30 Available to Order: Usually ships within 10 days.
#11	24-17032	SPRING (1 required per assembly)
		24-17032 - Spring, Lock Pin [ More info ] $3.10 Available to Order: Usually ships within 10 days.
#12	17030	SLEEVEE (1 required per assembly)
		17030 - Sleeve [ More info ] $9.20 Available to Order: Usually ships within 10 days.
#13	12-17029	WASHER (2 required per assembly)
		12-17029 - Washer, Cap Spring [ More info ] $3.10 Available to Order: Usually ships within 10 days.
#14	16847	THROTTLE LEVER (1 required per assembly)
		16847 - Throttle Lever [ More info ] $66.31 1 In Stock.
#15	17026	BRACKET (1 required per assembly)
		17026 - Bracket [ More info ] $27.17 Available to Order: Usually ships within 10 days.
#16	17027	CAP (1 required per assembly)
		17027 - Bracket Cap [ More info ] $18.60 Available to Order: Usually ships within 10 days.
#17	24-17028	SPRING (1 required per assembly)
		24-17028 - Spring, Bracket Cap [ More info ] $3.00 Available to Order: Usually ships within 10 days.
#18	13-16221	LOCKWASHER (1 required per assembly)
		13-16221 - Wave Washer [ More info ] $3.50 Available to Order: Usually ships within 10 days.
#19	26-16219	SEAL (1 required per assembly)
		26-16219 - Seal [ More info ] Unavailable
#20	23-16220	BUSHING (1 required per assembly)
		23-16220 - Bushing [ More info ] $6.50 Available to Order: Usually ships within 10 days.
#21	17023	BRACKET (1 required per assembly)
		17023 - Bracket [ More info ] $87.83 Available to Order: Usually ships within 10 days.
#22	10-16832	BOLT (2 required per assembly)
		10-16832 - Bolt [ More info ] $4.30 Available to Order: Usually ships within 10 days.
#23	13-40025 6	LOCKWASHER (2 required per assembly)
		13-40025 6 - LockWasher - Priced Individually [ More info ] $1.70 $0.96 10+ In Stock.
#24	11-40021 2	NUT (2 required per assembly)
		11-40021 2 - Nut [ More info ] $2.80 10+ In Stock.
#25	17024	STEERING HOOK PLATE (1 required per assembly)
		17024 - Plate [ More info ] $46.33 $39.38 2 In Stock.
#26	10-40003 54	BOLT (2 required per assembly)
		10-40003 54 - Screw - Priced Individually [ More info ] $4.60 9 In Stock.
#27	12-16192	WASHER (2 required per assembly)
		12-16192 - Washer [ More info ] $3.50 Available to Order: Usually ships within 10 days.
#28	13-17025	LOCKWASHER (2 required per assembly)
		13-17025 - LockWasher, NLA [ More info ] $2.10 $0.42 10+ In Stock.
#29	11-40021 3	NUT (2 required per assembly)
		11-40021 3 - Nut - Priced Individually [ More info ] $2.80 Available to Order: Usually ships within 10 days.
#30	87-17171	STOP SWITCH (1 required per assembly)
		87-17171 - Stop Switch [ More info ] Unavailable
		87-823037A 2 - Switch -Lanyard [ More info ] $89.17 Available to Order: Usually ships within 10 days.
#31	84-17162	HARNESS (5.9M) (1 required per assembly)
		84-17162 - Harness Assembly [ More info ] $116.13 1 In Stock.
#32	25-16226	GROMMET (1 required per assembly)
		25-16226 - Grommet [ More info ] $7.70 Available to Order: Usually ships within 10 days.
#33	10-17174	BOLT (1 required per assembly)
		10-17174 - BOLT,NLA [ More info ] Unavailable
#34	12-16080	WASHER (1 required per assembly)
		12-16080 - Washer, Stainless Steel [ More info ] Unavailable
		128M0108373 - Washer [ More info ] $1.40 1 In Stock.
#35	54-17169	CLAMP (1 required per assembly)
		54-17169 - Clamp [ More info ] $3.20 Available to Order: Usually ships within 10 days.
#36	11-40021 1	NUT (1 required per assembly)
		11-40021 1 - Nut [ More info ] $3.50 8 In Stock.
