Parts for MerCruiser 350 Mag MPI Alpha / Bravo Closed Cooling System - Alpha

Revise Search: All Models > 350 Mag MPI Alpha / Bravo > 0W650000 - 1A299999 > Closed Cooling System - Alpha

NEED PARTS OR KITS?
• View diagram and parts list below.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	32-863489	HOSE, Power Steering to Check Valve (1 required per assembly)
		32-863489 - Hose [ More info ] $67.17 Available to order: Usually ships within 8 days.
#2	21-864206A 1	CHECK VALVE ASSEMBLY (1 required per assembly)
		21-864206A 1 - Check Valve [ More info ] $28.30 $24.24 Available to order: Usually ships within 8 days.
#3	32-863623	HOSE, Check Valve to Fuel Cooler (1 required per assembly)
		32-863623 - Hose [ More info ] $34.34 Available to order: Usually ships within 8 days.
#4	32-864551	HOSE, Intake Bypass to Circulating Pump (1 required per assembly)
		32-864551 - Hose [ More info ] $17.70 $15.15 Available to order: Usually ships within 8 days.
#5	32-864431	HOSE, Distribution Fitting to Heat Exchanger (1 required per assembly)
		32-864431 - Hose [ More info ] $39.50 Available to order: Usually ships within 8 days.
#6	32-864539	HOSE, Thermostat Housing to Upper Manifold (1 required per assembly) Starboard, Non- Riser
		32-864539 - Hose [ More info ] $25.80 $22.10 2 in stock.
#6	32-864956	HOSE, Thermostat Housing to Upper Manifold (1 required per assembly) Starboard (1.7 Inch, 3 Inch, 4.7 Inch and 6 Inch Riser)
		32-864956 - Hose [ More info ] $29.33 2 in stock.
#7	32-864552	HOSE, Thermostat Housing to Upper Manifold (1 required per assembly) Port, Non-Riser
		32-864552 - Hose [ More info ] $23.66 2 in stock.
#7	32-864954	HOSE, Thermostat Housing to Upper Manifold (1 required per assembly) Port (1.7 Inch, 3 Inch, 4.7 Inch and 6 Inch Riser)
		32-864954 - Hose [ More info ] $37.20 $31.85 2 in stock.
#8	32-864509	HOSE, Thermostat Housing to Lower Manifold (1 required per assembly) Starboard
		32-864509 - Hose [ More info ] $46.00 Available to order: Usually ships within 8 days.
#9	32-864508	HOSE, Thermostat Housing to Lower Manifold (1 required per assembly) Port
		32-864508 - Hose [ More info ] $34.16 Available to order: Usually ships within 8 days.
#10	32-863670	HOSE, Fuel Cooler to Accumulator Housing (1 required per assembly)
		32-863670 - Hose [ More info ] $25.41 Available to order: Usually ships within 8 days.
#11	32-864506	HOSE, Heat Exchanger to Thermostat Housing (1 required per assembly)
		32-864506 - Hose [ More info ] $17.00 $14.56 Available to order: Usually ships within 8 days.
#12	32-864507	HOSE, Heat Exchanger to Thermostat Housing (1 required per assembly)
		32-864507 - Hose [ More info ] $15.80 Available to order: Usually ships within 8 days.
#13	32-864542	HOSE, Heat Exchanger to Starboard Elbow (1 required per assembly) (Non Riser, 1.7 Inch and 3 Inch Riser)
#13	32-864955	HOSE, Heat Exchanger to Starboard Elbow (1 required per assembly) (4.7 Inch and 6 Inch Riser)
		32-864955 - Hose [ More info ] $36.00 $30.83 2 in stock.
#14	32-864726	HOSE, Heat Exchanger to Port Elbow (1 required per assembly) (Non Riser, 1.7 Inch and 3 Inch Riser)
		32-864726 - Hose [ More info ] $28.67 Available to order: Usually ships within 8 days.
#14	32-864953	HOSE, Heat Exchanger to Port Elbow (1 required per assembly) (4.7 Inch and 6 Inch Riser)
		32-864953 - Hose [ More info ] $30.50 2 in stock.
#15	32-863611	HOSE, Sea Pump to Power Steering Cooler (1 required per assembly)
		32-863611 - Hose [ More info ] $52.33 Available to order: Usually ships within 8 days.
#16	54-815504212	CLAMP, Worm Gear (1 required per assembly)
		54-815504212 - Clamp [ More info ] $4.30 Available to order: Usually ships within 8 days.
#17	54-815504216	CLAMP, Worm Gear (1.56 Diameter) (1 required per assembly)
		54-815504216 - Clamp [ More info ] $13.10 Available to order: Usually ships within 8 days.
#18	54-815504222	CLAMP, Worm Gear (1.98 DIameter) (1 required per assembly)
		54-815504222 - Clamp - Priced Individually [ More info ] $4.50 Available to order: Usually ships within 8 days.
#19	54-815504228	CLAMP, Worm Gear (1 required per assembly)
		54-815504228 - Clamp [ More info ] $14.80 Available to order: Usually ships within 8 days.
#20	54-815504232	CLAMP, Worm Gear (2.50 Diameter) (1 required per assembly)
		54-815504232 - Clamp [ More info ] $6.40 $3.58 10+ in stock.
#21	32-864886	HOSE, Heat Exchanger to Circulating Pump (1 required per assembly)
		32-864886 - Hose [ More info ] $33.59 Available to order: Usually ships within 8 days.
#22	54-815504224	CLAMP, Worm Gear (1 required per assembly)
		54-815504224 - Clamp [ More info ] $3.70 Available to order: Usually ships within 8 days.
#23	864395T01	HEAT EXCHANGER, Closed Cooling (1 required per assembly)
		864395T01 - Heat Exchanger [ More info ] $1,967.50 $955.50 1 in stock.
		864395A03 - Cooling Kit, FWC, MEFI3 [ More info ] $1,100.00 1 in stock.
#24	864708	COVER, End, Heat Exchanger (2 required per assembly)
		864708 - Heat Exchanger Cover [ More info ] $75.50 Available to order: Usually ships within 8 days.
#25	25-818679	O-RING (4 required per assembly)
		25-818679 - O-Ring - Priced Individually [ More info ] $6.00 Available to order: Usually ships within 8 days.
#26	10-94247	SCREW, (.375-16 x .750) Stainless Steel (2 required per assembly)
		10-94247 - Screw - Priced Individually [ More info ] $2.20 Available to order: Usually ships within 8 days.
#27	25-866152	SEAL (2 required per assembly)
		27-866152 - 27-866152 - SEAL * [ More info ] Unavailable Replaced by 25-8M0084884
		25-8M0084884 - SEAL [ More info ] Unavailable
#28	36-814879 1	CAP, Pressure (1 required per assembly)
		36-814879 1 - Pressure Cap [ More info ] $50.90 $43.58 Available to order: Usually ships within 8 days.
#29	10-805559	SCREW, (.375-16 x .875) Stainless Steel (1 required per assembly)
		10-805559 - Screw [ More info ] $7.40 1 in stock.
#30	10-34353	SCREW, (.375-16 x 1.00) (3 required per assembly)
		10-34353 - Screw - Priced Individually [ More info ] $1.90 10+ in stock.
#31	54-815504396	CLAMP, Worm Gear, Heat Exchanger (1 required per assembly)
		54-815504396 - Clamp [ More info ] $22.80 $19.52 1 in stock.
#32	71587A10	RECOVERY KIT, Coolant (1 required per assembly)
		71587A10 - Coolant Recovery Kit [ More info ] $67.17 Available to order: Usually ships within 8 days.
#33	71587A11	BOTTLE, Plastic, Coolant Recovery Kit (1 required per assembly)
		71587A11 - Coolant Recovery Bottle [ More info ] $54.25 Available to order: Usually ships within 8 days.
#34	72058	CAP, Coolant Recovery Bottle (1 required per assembly)
		72058 - Bottle Cap [ More info ] $7.60 Available to order: Usually ships within 8 days.
#35	32-865672079	HOSE, (96.00 Inches Bulk), Sea Water Pump to Water Pick Up (1 required per assembly)
		32-865672079 - 32-865672079 - HOSE (96.00 Inche O [ More info ] Unavailable Replaced by 32-8M0062666
		32-8M0062666 - Water Hose Bulk -96" [ More info ] $186.60 $159.78 In stock
#36	18431	PAD, Heat Exchanger (1 required per assembly)
		18431 - Pad [ More info ] $25.16 Available to order: Usually ships within 8 days.
#37	864494T	BRACKET, Cooler (1 required per assembly)
		864494T - Heat Exchanger Bracket [ More info ] $134.66 Available to order: Usually ships within 8 days.
#38	32-864533	HOSE (1 required per assembly)
		32-864533 - Hose [ More info ] $27.00 $23.13 Available to order: Usually ships within 8 days.
#39	863841T	TUBE, Water, Brass (1 required per assembly) Compact Hydralic Steering
		863841T - Tube - Extender [ More info ] $112.83 1 in stock.
#40	22-806608A 1	PLUG KIT, (.500-13) Royal Blue (1 required per assembly)
		22-806608A 1 - 22-806608A 1 - PLUG KIT (.500-13 O [ More info ] Unavailable Replaced by 22-806608A02
		22-806608A02 - 22-806608A02 - PLUG ASSEMBLY (.5 [ More info ] Unavailable Replaced by 22-8M0119211
		22-8M0119211 - Plug Assembly (.500-13) [ More info ] $7.00 Available to order: Usually ships within 8 days.
		18-4226 - Blue Drain Plug, 22-806608A1 [ More info ] $4.49 $2.97 10+ in stock.
		22-806608Q01 - Plug Kit - Priced Individually [ More info ] $7.00 Available to order: Usually ships within 8 days.
#41	25-32509	O-RING, (.489 x .070) (1 required per assembly)
		25-32509 - O-Ring - Priced Individually [ More info ] $1.50 10+ in stock.
		18-7165-9 - O-Ring (PK5) , 0304174 [ More info ] $7.45 $4.08 1 in stock.
#42	32-19833 89	HOSE, Included with Coolant Recovery Kit (1 required per assembly)
		32-19833 89 - Hose [ More info ] $29.09 Available to order: Usually ships within 8 days.
