Parts for Mariner 30A Intake Manifold
Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
| # | 811038M | CARBURETOR REPAIR KIT |
  |
|
811038M - Carburetor Repair Kit [ More info ]
|
| #1 | 811031M | AIR INTAKE COVER (INNER) (1 required per assembly) |
 |
|
811031M - Cover, NLA [ More info ] Unavailable |
| #2 | 95682M | AIR INTAKE COVER (OUTER) (1 required per assembly) |
|
|
95682M - Air Intake Cover, NLA [ More info ]
|
| #3 | 10-811032M | SCREW (2 required per assembly) |
|
|
10-811032M - Screw, NLA [ More info ]
|
| #4 | 10-811033M | SCREW (1 required per assembly) |
|
|
10-811033M - Screw, NLA [ More info ]
|
| #5 | 25-84757M | O-RING (1 required per assembly) |
|
|
25-84757M - O-Ring [ More info ]
|
| #6 | 17-84762M | ROLL PIN (1 required per assembly) |
|
|
17-84762M - Pin -roll, NLA [ More info ]
|
| #7 | 84763M | ROD (1 required per assembly) |
|
|
|
| #8 | 81191M | RETAINER (1 required per assembly) |
|
81191M - Connector [ More info ] Unavailable |
|
  |
|
16333 - Rod Snap [ More info ] Unavailable |
| #9 | 84761M | CHOKE LEVER (1 required per assembly) |
|
|
84761M - Choke Lever [ More info ] Unavailable |
| #10 | 83960M | CHOKE KNOB (1 required per assembly) |
|
|
83960M - Choke Knob, NLA [ More info ] Unavailable |
| #11 | 25-84760M | GROMMET (1 required per assembly) |
|
|
25-84760M - Grommet, Choke Knob,NLA [ More info ]
|
| #12 | 12-82214M | WASHER (11 required per assembly) |
|
|
12-82214M - Washer - Priced Individually [ More info ]
|
| #13 | 11-82389M | NUT (2 required per assembly) |
|
|
11-82389M - Nut, NLA [ More info ] Unavailable |
| #14 | 27-80572M | GASKET (1 required per assembly) |
|
|
27-80572M - Carburetor Manifold Gasket [ More info ]
|
|
|
27-80572 - Carburetor Manifold Gasket [ More info ]
|
| #15 | 16-811028M | STUD (2 required per assembly) |
|
|
16-811028M - Stud, NLA [ More info ]
|
| #16 | 811027M | REED VALVE ASSEMBLY (1 required per assembly) |
|
|
811027M - Reed Valve [ More info ]
|
| #17 | 34-84759M | REED SET (REED STOPS NOT INCLUDED) (1 required per assembly) |
|
|
34-84759M - Reed Kit, NLA [ More info ]
|
| #18 | 27-80569M | GASKET- MANUAL (1 required per assembly) |
  |
|
27-80569M - Intake Manifold Gasket [ More info ]
|
| #19 | 27-80571M | GASKET - MANUAL (1 required per assembly) |
|
|
27-80571M - Intake Manifold Gasket [ More info ]
|
| #20 | 27-811029M | GASKET- ELECTRIC (1 required per assembly) |
|
|
27-811029M - Intake Manifold Gasket [ More info ]
|
| #21 | 27-811030M | GASKET - ELECTRIC (1 required per assembly) |
|
|
27-811030M - Intake Manifold Gasket [ More info ]
|
| #22 | 80570M | INTAKE MANIFOLD (1 required per assembly) |
|
80570M - Intake Manifold [ More info ] Unavailable |
|
|
|
80570002 - MANIFOLD Intake NLA [ More info ] Unavailable |
| #23 | 54-96348M | CLAMP (1 required per assembly) |
|
|
54-96348M - Clamp [ More info ]
|
| #24 | 10-82405M | BOLT (2 required per assembly) |
|
|
10-82405M - Screw, NLA [ More info ]
|
| #25 | 10-83285M | BOLT (7 required per assembly) |
  |
|
10-83285M - Screw - Priced Individually [ More info ]
|
| #26 | 12-83768M | WASHER - ELECTRIC (1 required per assembly) |
|
|
12-83768M - Washer, NLA [ More info ]
|
| #27 | 54-814589M | CLAMP - ELECTRIC (1 required per assembly) |
|
|
54-814589M - Clamp [ More info ]
|
