Parts for Chrysler 4 HP (1981) Carburetor & Reed Plate

Revise Search: All Models > 4 HP (1981) > 43H1H ( ) > Carburetor & Reed Plate

NEED PARTS OR KITS?
View diagram and parts list below.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

Engine section

Reference numbers in this diagram can be found in a light blue row below — scroll down to order.
Each product listed is an OEM or aftermarket equivalent part. [ Example ]

#1	F521168	GASKET, CARBURETOR ADAPTER (1 required per assembly)
		27-F521168 - Gasket, NLA [ More info ] $2.00 10+ in stock.
#2	F2A332167	CARBURETOR ADAPTER (1 required per assembly) W/ILLUS. 7, 10, 11 AND 12
		F2A332167 - ADAPTER ASSEMBLY O NLA [ More info ] Unavailable
#3	F1532	HEX CAP SCREW, 1/4 - 20 X 1 (4 required per assembly)
		10-F1532 - Screw [ More info ] $0.40 10+ in stock.
		10-819110100 - Screw [ More info ] $1.40 Available to order: Usually ships within 8 days.
#4	F8060	INTERNAL TOOTH LOCKWASHER (4 required per assembly)
		13-F8060 - LockWasher, NLA [ More info ] $1.25 10+ in stock.
#7	F433209-1	STUD, CARBURETOR (1 required per assembly)
		16-F433209-1 - Stud [ More info ] $8.00 10+ in stock.
#9	F521906	GASKET, CARBURETOR (1 required per assembly)
		27-F521906 - Gasket [ More info ] $1.80 3 in stock.
#10	F31160-1	REED (1 required per assembly)
		F31160-1 - F31160-1 - REED O [ More info ] Unavailable Replaced by 34-F31160-2
		34-F31160-2 - Reed, NLA [ More info ] $18.00 10+ in stock.
#11	F424161	REED STOP (1 required per assembly)
		34-F424161 - Reed Stop, NLA [ More info ] $5.00 10+ in stock.
#12	F1755	ROUND HD SCREW W/LOCKWASHER, 6 - 32 X 5/16 (2 required per assembly)
		F1755 - F1755 - SCREW AND LOCKWAS O [ More info ] Unavailable Replaced by 10-819074
		10-819074 - Screw -w/Lw [ More info ] $0.80 10+ in stock.
#13	F521550	KNOB, FUEL SHUT-OFF (1 required per assembly)
		F521550 - KNOB O NLA [ More info ] Unavailable
#14	F521489	VALVE, FUEL SHUT-OFF (1 required per assembly)
		20-F521489 - Valve, NLA [ More info ] $30.00 10+ in stock.
#15	F10071	SCREW (1 required per assembly)
		F10071 - F10071 - SCREW O [ More info ] Unavailable Replaced by 1395-5902
		1395-5902 - Screw Assembly, NLA [ More info ] $5.00 10+ in stock.
#16	F10060	THROTTLE (1 required per assembly)
		F10060 - VALVE Throttle O NLA [ More info ] Unavailable
#17	F521061-6	CARBURETOR - COMPLETE (1 required per assembly)
#18	F10075	SPRING, THROTTLE RETURN (1 required per assembly)
		F10075 - SPRING O NLA [ More info ] Unavailable
#19	F10059	THROTTLE SHAFT (1 required per assembly)
		F10059 - Shaft And Lever [ More info ] $10.00 3 in stock.
#20	F10061	CHOKE SHAFT (1 required per assembly)
		F10061 - SHAFT Choke O NLA [ More info ] Unavailable
#21	F10072	SPRING, CHOKE STOP (1 required per assembly)
		F10072 - SPRING O NLA [ More info ] Unavailable
#22	F10073	SPRING, IDLE ADJUSTMENT NEEDLE (1 required per assembly)
		F10073 - SPRING O NLA [ More info ] Unavailable
#23	F10077	NEEDLE, IDLE (1 required per assembly)
		F10077 - Idle Needle [ More info ] $10.10 7 in stock.
#24	F10062	CHOKE VALVE (1 required per assembly)
		F10062 - Valve Assembly, NLA [ More info ] $2.50 1 in stock.
#25	F10070	SCREW, CHOKE VALVE (2 required per assembly)
		F10070 - SCREW O NLA [ More info ] Unavailable
#26	F1490	HEX NUT, 1/4 - 20 (2 required per assembly)
		11-F1490 - 11-F1490 - NUT O [ More info ] Unavailable Replaced by 11-20890
		11-20890 - Nut - Priced Individually [ More info ] $1.20 10+ in stock.
#27	F10065	NOZZLE (1 required per assembly)
		F10065 - Nozzle, NLA [ More info ] $6.00 5 in stock.
#28	F10066	GASKET, VALVE SEAT (1 required per assembly)
		26-F10066 - 26-F10066 - GASKET O [ More info ] Unavailable Replaced by 1395-8944
		1395-8944 - Gasket [ More info ] $2.20 10+ in stock.
#29	F10100	VALVE, SEAT AND GASKET ASSEMBLY (1 required per assembly)
		F10100 - F10100 - VALVE O [ More info ] Unavailable Replaced by -F10100-1
		F10100-1 - VALVE KIT O [ More info ] Unavailable
#30	F10063	FLOAT (1 required per assembly)
		F10063 - F10063 - FLOAT O [ More info ] Unavailable Replaced by 1395-5898
		1395-5898 - FLOAT O NLA [ More info ] Unavailable
#31	F10064	FLOAT PIN (1 required per assembly)
		F10064 - Float Support Shaft [ More info ] $3.10 Available to order: Usually ships within 8 days.
#32	F10068	GASKET, FUEL BOWL (1 required per assembly)
		27-F10068 - Gasket [ More info ] $3.40 Available to order: Usually ships within 8 days.
#33	F10090	GASKET, BOWL RETAINER (2 required per assembly)
		27-F10090 - Gasket [ More info ] $2.50 10+ in stock.
#34	F10058	FUEL BOWL (1 required per assembly)
		F10058 - Bowl [ More info ] $25.84 1 in stock.
		1395-8155 - BOWL Fuel O NLA [ More info ] Unavailable
#35	F10084	SPRING, FLOAT SUPPORT (1 required per assembly)
		F10084 - F10084 - SPRING O [ More info ] Unavailable Replaced by 1395-5904
		1395-5904 - Spring, NLA [ More info ] $11.50 10+ in stock.
#36	F10096	JET ASSEMBLY (.039) STD. SEA LEVEL - 3000 FT. (1 required per assembly)
		F10096 - F10096 - JET O [ More info ] Unavailable Replaced by 1395-6525
		1395-6525 - JET-.039 O NLA [ More info ] Unavailable
#-	F10093	JET ASSEMBLY (.038) OPT. 3000 FT. - 5000 FT. (- required per assembly)
		F10093 - F10093 - NEEDLE ASSEMBLY O [ More info ] Unavailable Replaced by 1395-6526
		1395-6526 - JET-.038 O NLA [ More info ] Unavailable
#-	F10086	JET ASSEMBLY (.037) OPT. 5000 FT. - 7000 FT. (- required per assembly)
		F10086 - JET O NLA [ More info ] Unavailable
#-	F10094	JET ASSEMBLY (.036) OPT. 7000 FT. AND UP (- required per assembly) OPTIONAL SIZE MAIN FUEL JETS (USE ONLY AT ALTITUDES INDICATED)
		F10094 - JET O NLA [ More info ] Unavailable
#41	F1534	HEX CAP SCREW, 1/4 - 20 X 7/8 (2 required per assembly)
		F1534 - F1534 - SCREW O [ More info ] Unavailable Replaced by 10-F2008
		10-F2008 - Screw -ss, NLA [ More info ] $2.00 10+ in stock.
#42	F521708	CARBURETOR COVER (1 required per assembly)
		F521708 - COVER Carburetor O NLA [ More info ] Unavailable
#43	F1064	FILL HD SCREW, 8 - 32 X 3/8 (2 required per assembly)
		10-F1064 - Screw -ss [ More info ] $0.80 9 in stock.
#44	F8078	LOCKWASHER, INTERNAL TOOTH (2 required per assembly)
		F8078 - F8078 - LOCKWASHER O [ More info ] Unavailable Replaced by 13-23836
		13-23836 - LockWasher, NLA [ More info ] $1.50 10+ in stock.
#45	F10098	*REPAIR KIT. (1 required per assembly) INCLUDES ALL ITEMS MARKED WITH AN ASTERISK ()**
		F10098 - F10098 - REPAIR KIT O [ More info ] Unavailable Replaced by -FK10098
		FK10098 - Carburetor Repair Kit, NLA [ More info ] $55.00 1 in stock.
#46	F10069	GASKET SET. (1 required per assembly) INCLUDES ALL ITEMS MARKED WITH A DOUBLE ASTERISK ()**
		F10069 - F10069 - GASKET SET O [ More info ] Unavailable Replaced by -FK10069
		FK10069 - Carburetor Gasket Set, NLA [ More info ] $18.00 10+ in stock.
